Rectangular rechargeable battery pack, dark casing, 71.75 by 39.61 by 21.44 mm, 105 g

Cameron Sino Battery For Hioki 3400mAh 25.16Wh 7.4V

SKU CH-F11J-N73QT

Replacement 3400 mAh 25.16 Wh 7.4 V battery for Hioki LR8410, LR8510, LR8511 and Topcon survey instruments

  • Capacity (mAh)3400mAh / 25.16Wh
  • 3400 mAh capacity powers Hioki LR8410 LR8510 LR8511 longer
  • 4 V 25.16 Wh matches original Z1007 specifications exactly
  • Fully decoded chip works like the factory battery
  • ISO9001 RoHS CE certified for safe reliable use
  • Compact 71.75 x 39.61 x 21.44 mm fits equipment neatly

Compatible Hioki Models

This replacement battery fits Hioki LR8410, LR8510 and LR8511 instruments. It is built for survey and test professionals who need a reliable power source for field equipment. The 3400mAh capacity and 7.4V output match the original Z1007 specification. It is not for users with other Hioki models or different part numbers.

Verify Device And Part Number

Before ordering, confirm your instrument shows LR8410, LR8510 or LR8511 on its label and that the original battery carries part number Z1007. Check that the connector on your existing pack matches the replacement. A new pack reaches full performance after two or three complete charge and discharge cycles. Do not install if the connector does not seat securely.

Thermals And Protection

The cell includes overcharge, over-discharge, over-voltage and short-circuit protection for safe operation. Store the battery below 60°C to avoid damage. Dimensions are 71.75 x 39.61 x 21.44mm and weight is 105g. The pack is rechargeable and certified to ISO9001, RoHS and CE standards. Avoid disassembly, fire or water exposure.

Highlights

  • 3400 mAh capacity powers Hioki LR8410 LR8510 LR8511 longer
  • 4 V 25.16 Wh matches original Z1007 specifications exactly
  • Fully decoded chip works like the factory battery
  • ISO9001 RoHS CE certified for safe reliable use
  • Compact 71.75 x 39.61 x 21.44 mm fits equipment neatly

Specifications

Brandcameron sino
ModelBattery For Hioki
Capacity (mAh)3400mAh / 25.16Wh

Questions about this item

What comes in the box with the Cameron Sino battery and do I need to buy a charger separately?

The package includes one 3400mAh 7.4V rechargeable battery with a decoded chip and shock-protective foam; a compatible charger for the Hioki LR8410, LR8510 or LR8511 must be sourced separately.

How do I choose the right version for my Hioki logger or Topcon survey instrument?

Match the device model — this battery replaces Hioki part Z1007 and fits LR8410, LR8510, LR8511 loggers plus Topcon FC100, FC2000, FC-100, FC-120, FC-200, FC-2200, FC-2500 units.

What does the 25.16Wh rating mean for actual runtime in my Hioki LR8510?

At 7.4V and 3400mAh the pack stores 25.16Wh; real operating time depends on the logger's power draw, but the capacity matches the original Z1007 specification.
