Rectangular lithium-polymer battery pack, dark plastic casing, connector on one end, 83.6 by 47 by 12.1 mm

Cameron Sino Battery for Dranetz HDPQ-SP Series 700mAh 9.6V

SKU CH-JZPG-H0C66

Replacement 9.6 V, 700 mAh lithium-polymer pack fits Dranetz HDPQ-SP Guide, Visa, Xplorer and Xplorer400 analysers

  • Specifications83.60 x 47.00 x 12.10
  • Battery Pack83.60 x 47.00 x 12.10
  • Battery Capacity700.00 milliamp_hours
  • Battery Voltage9.6 volts
  • Replaces original Dranetz BP-HDPQ-SP battery for HDPQ-SP series
  • 700 mAh capacity and 9.6 V voltage deliver 6.72 Wh of energy
  • Certified to ISO 9001, RoHS and CE standards for safety
  • Compact 83.60 × 47.00 × 12.10 mm size fits the instrument
  • Built-in protection against overcharge, over-discharge, over-voltage and short circuits

Replacement Battery for Dranetz HDPQ-SP Series

This 700mAh lithium-polymer pack replaces the original BP-HDPQ-SP cell in HDPQ-SP-Guide, HDPQ-SP-Visa, HDPQ-SP-Xplorer and HDPQ-SP-Xplorer400 analysers. It supplies 9.6 volts and 6.72 Wh for field survey and test work. The pack fits the same 83.60 x 47.00 x 12.10 mm cavity as the factory unit.

Sustained Capacity and Protection

A fully decoded chip manages charge and discharge cycles so the meter reads accurately from the first use. Overcharge, over-discharge, over-voltage and short-circuit protection circuits guard the cells during long logging sessions. The 700.00 mAh rating is maintained across the operating range rather than only in a brief benchmark.

Build Quality and Day-to-Day Fit

Each pack weighs 103.0 g and ships in shock-absorbing foam to survive transit. ISO9001, RoHS and CE markings confirm the manufacturing standard. Installers should verify the model number and part number before fitting, and allow two or three full cycles for the pack to reach its settled capacity. Buyers needing a higher-capacity cell or a different voltage will need a different pack.

Highlights

  • Replaces original Dranetz BP-HDPQ-SP battery for HDPQ-SP series
  • 700 mAh capacity and 9.6 V voltage deliver 6.72 Wh of energy
  • Certified to ISO 9001, RoHS and CE standards for safety
  • Compact 83.60 × 47.00 × 12.10 mm size fits the instrument
  • Built-in protection against overcharge, over-discharge, over-voltage and short circuits

Specifications

BrandCameron Sino
ModelHDPQ-SP-Guide, HDPQ-SP-Visa, HDPQ-SP-Xplorer, HDPQ-SP-Xplorer400
Part NumberBP-HDPQ-SP
Specifications83.60 x 47.00 x 12.10
Battery Pack83.60 x 47.00 x 12.10
Battery Capacity700.00 milliamp_hours
Battery Voltage9.6 volts

Questions about this item

Does the 9.6 V lithium-polymer pack run hot during continuous use in a Dranetz HDPQ-SP analyser?

The battery is rated for operation up to 60 °C / 140 °F; normal analyser loads keep it well within that range.

What must I already own for this BP-HDPQ-SP replacement to work?

A Dranetz HDPQ-SP-Guide, HDPQ-SP-Visa, HDPQ-SP-Xplorer or HDPQ-SP-Xplorer400 unit that takes the original BP-HDPQ-SP pack.

Will the 700 mAh capacity match the runtime of the original battery in my older HDPQ-SP-Xplorer?

Yes — it is built to the same 700 mAh / 6.72 Wh specification and uses a fully decoded chip so the analyser reports capacity identically.
