White rectangular lithium battery, 53.30 by 16.10 by 14.90 mm, labelled 3.6V 2000mAh

Cameron & Co

Cameron & Co DS-CS-YMC110SL standard battery 3.6V 2000mAh white

SKU CH-4HTY-88RB7

3.6 V lithium-manganese dioxide primary cell rated at 2000 mAh, built to replace Yaskawa ER6BD-WK77P packs in YRC1000 controllers

  • TypeBattery
  • Compatible with Yaskawa YRC1000 systems
  • Primary Li-MnO2 chemistry, non-rechargeable
  • 6 V 2000 mAh delivers 7.2 Wh capacity
  • Compact 53.30 x 16.10 x 14.90 mm form factor
  • White housing matches original equipment appearance

Cameron & Co DS-CS-YMC110SL battery

The Cameron & Co DS-CS-YMC110SL is a 3.6 V lithium-manganese dioxide primary cell rated at 2000 mAh. It serves as a direct replacement for Yaskawa ER6BD-WK77P and ER6BDWK77P batteries used in YRC1000 controllers. Industrial maintenance teams and automation engineers fitting backup power to these systems are the intended users.

Installing the cell

The battery measures 53.30 by 16.10 by 14.90 mm and slides into the controller's dedicated compartment. Polarity must match the original ER6BD-WK77P orientation; reversing it will prevent the YRC1000 from recognising the backup supply. Because the cell is non-rechargeable, do not attempt to charge it in-circuit or externally.

Checks before ordering

Verify that your controller is a YRC1000 and that the existing part number is ER6BD-WK77P or ER6BDWK77P. Confirm the compartment accepts the listed dimensions and that the system expects a 3.6 V primary lithium chemistry. This product is not for setups requiring rechargeable cells or a different voltage.

Highlights

  • Compatible with Yaskawa YRC1000 systems
  • Primary Li-MnO2 chemistry, non-rechargeable
  • 6 V 2000 mAh delivers 7.2 Wh capacity
  • Compact 53.30 x 16.10 x 14.90 mm form factor
  • White housing matches original equipment appearance

Specifications

BrandCameron Sino
ModelDS-CS-YMC110SL
TypeBattery

Questions about this item

How can I confirm the 3.6V 2000mAh battery is working after installing it in my YRC1000?

The YRC1000 should power on and retain its memory settings without low-voltage warnings; a multimeter reading near 3.6 V at the terminals also confirms the cell is healthy.

What comes in the box and do I need any extra parts for the YRC1000 installation?

One white Li-MnO2 primary cell measuring 53.30 x 16.10 x 14.90 mm is supplied; no charger, cable or adapter is included or required for this non-rechargeable battery.

Which capacity should I choose for the ER6BD-WK77P replacement — 2000mAh or a different value?

This model is offered only in the 2000mAh / 7.2 Wh capacity, matching the original ER6BD-WK77P specification for the YRC1000.
