Yellow rectangular Li-MnO2 battery with black connector

Cameron & Co

Cameron & Co DS-CS-FN500SL 6.0V 2.9Ah Li-MnO2 standard battery

SKU CH-7608-RVF4N

6.0 V 2.9 Ah lithium manganese dioxide cell replaces Panasonic A98L-0031-0025 and BR-2/3AGCT4A in FANUC ALPHA iSV and BETA iSV amplifiers plus Allen-Bradley SLC 500 and MicroLogix controllers

  • TypePower Tool
  • Replaces Panasonic A98L-0031-0025 and BR-2/3AGCT4A directly
  • Powers FANUC ALPHA iSV and BETA iSV amplifiers reliably
  • Fits Allen-Bradley SLC 500 and MicroLogix controllers precisely
  • Non-rechargeable Li-MnO2 chemistry delivers 6.0 V and 2.9 Ah
  • Compact yellow pack measures 46.12 x 33.70 x 34.86 mm

Industrial backup power

The Cameron & Co DS-CS-FN500SL is a 6.0V 2.9Ah lithium manganese dioxide battery built for GE FANUC ALPHA iSV and BETA iSV amplifiers. It also fits Allen-Bradley SLC 500 and MicroLogix controllers including the 1747-L511 through 1747-L553 models. The yellow cell delivers 17.40Wh of non-rechargeable capacity for memory retention in automation equipment.

Direct plug-in replacement

Installation consists of removing the old cell and pressing the black connector onto the board header; no soldering or tools are required. The 46.12 x 33.70 x 34.86 mm form factor matches the original Panasonic A98L-0031-0025 and BR-2/3AGCT4A packs. Polarity is fixed by the keyed connector, so reverse insertion is prevented.

Primary chemistry limits

Li-MnO2 cells cannot be recharged, so the unit must be replaced once voltage drops below the controller threshold. Self-discharge is low but not zero, meaning spares stored for years should be checked before deployment. The single 2900mAh capacity fixes the backup duration; there is no provision for paralleling cells to extend runtime.

Highlights

  • Replaces Panasonic A98L-0031-0025 and BR-2/3AGCT4A directly
  • Powers FANUC ALPHA iSV and BETA iSV amplifiers reliably
  • Fits Allen-Bradley SLC 500 and MicroLogix controllers precisely
  • Non-rechargeable Li-MnO2 chemistry delivers 6.0 V and 2.9 Ah
  • Compact yellow pack measures 46.12 x 33.70 x 34.86 mm

Specifications

BrandCameron Sino
ModelDS-CS-FN500SL
TypePower Tool

Questions about this item

How can I verify the DS-CS-FN500SL is working after installing it in my FANUC ALPHA iSV amplifier?

Measure the output with a multimeter; a healthy cell reads about 6.0 V under no load and the amplifier should power up without a low-battery fault.

What comes in the box with the DS-CS-FN500SL and what must I source separately?

The package contains one yellow Li-MnO2 cell with its black connector fitted; no tools, mounting hardware or cables are included.

Which version of this battery matches a Panasonic A98L-0031-0025 or BR-2/3AGCT4A part number?

The DS-CS-FN500SL is the direct replacement — it is listed as compatible with both Panasonic A98L-0031-0025 and BR-2/3AGCT4A references.
