Cambium Networks
Cambium Networks PTP 550 5GHz Connectorized End access point
A 5 GHz point-to-point access point delivering up to 1.36 Gbps over distances up to 122 miles with IP66/67 protection
- StandardsIEEE 802.11ac
- Wireless Data RatesUp to 1.36 Gbps
- Frequency Band5.170 to 5.980 GHz
- Operating RangeUp to 122 miles (200 km)
- Interface1 x Gigabit Ethernet Copper port: Data + PoE power input / 1
- DimensionsConnectorized Outdoor Unit (ODU): Width 177mm (7”), Height 2
- Up to 1.36 Gbps wireless throughput for high-capacity backhaul
- IEEE 802.11ac Wave2 standard delivers gigabit-class performance
- 170 to 5.980 GHz frequency band supports flexible channel selection
- Dual Gigabit Ethernet copper and SFP ports enable fiber or copper uplinks
- IP66/67 metal enclosure protects against extreme conditions up to 122 miles
High-capacity 5 GHz backhaul radio
The Cambium Networks PTP 550 delivers up to 1.36 Gbps over a 5.170 to 5.980 GHz band using IEEE 802.11ac Wave 2 technology. It is built for service providers and enterprises that need licensed-performance throughput in point-to-point links spanning up to 122 miles.
Connectorized design with flexible fibre or copper
The outdoor unit measures 177 mm wide by 280 mm high by 89 mm deep and weighs 1.6 kg including its mounting bracket. A single Gigabit Ethernet copper port handles both data and PoE power input, while an SFP port accepts single-mode fibre, multi-mode fibre or copper modules for diverse backhaul topologies.
IP66/67 enclosure sustains throughput in extreme
Dynamic Spectrum Optimization continuously scans the band and shifts channels to avoid interference, maintaining link stability during prolonged operation. Efficient channel bonding with independent 80 MHz channels preserves the 1.36 Gbps rate over long distances without thermal throttling.
Highlights
- Up to 1.36 Gbps wireless throughput for high-capacity backhaul
- IEEE 802.11ac Wave2 standard delivers gigabit-class performance
- 170 to 5.980 GHz frequency band supports flexible channel selection
- Dual Gigabit Ethernet copper and SFP ports enable fiber or copper uplinks
- IP66/67 metal enclosure protects against extreme conditions up to 122 miles
Specifications
| Brand | Cambium Networks |
|---|---|
| Series | PTP |
| Model | PTP 550 |
| Standards | IEEE 802.11ac |
| Wireless Data Rates | Up to 1.36 Gbps |
| Frequency Band | 5.170 to 5.980 GHz |
| Operating Range | Up to 122 miles (200 km) |
| Interface | 1 x Gigabit Ethernet Copper port: Data + PoE power input / 1 x SFP port: single-mode fiber, multi-mode fiber or copper Gigabit Ethernet options available |
| Dimensions | Connectorized Outdoor Unit (ODU): Width 177mm (7”), Height 280mm (11”), Depth 89mm (3.5”) |
| Weight | Connectorized Outdoor Unit (ODU): 1.6 kg (3.5 lbs) including bracket |
Questions about this item
What throughput limit appears first when the PTP 550 runs two 80 MHz channels continuously?
The radio reaches 1.36 Gbps aggregate throughput with two 80 MHz channels bonded, which is the maximum wireless data rate specified for the PTP 550.
How much heat and noise does the sealed IP66/67 metal enclosure produce during all-day operation?
The passively cooled IP66/67 metal housing has no fans, so it generates no audible noise; heat is dissipated through the enclosure surface under solar radiation and ambient conditions.
Which external antennas and mounting hardware must I already have to install this connectorized end unit?
You need two 5 GHz antennas with N-type connectors, coaxial cables, and a mast or tower capable of supporting the 1.6 kg ODU with its included bracket.
