Green circuit board with silver SFP+ cage and black M.2 edge connector

C&N

C&N 10G M.2 Intel 82599 SFP+ network card

SKU CH-GJ51-TPKVG

M.2 M-key card adds a 10 Gbps SFP+ Ethernet port using an Intel 82599 controller

  • Speed10 gigabits_per_second
  • FeaturesDesktop
  • 10 Gbps throughput with Intel 82599EN controller
  • Single SFP+ port accepts fibre, DAC or AOC modules
  • PCIe 2.0 x4 lane fits x4, x8 and x16 slots
  • Broad OS support from Windows 7 to Server 2022 and Linux
  • M.2 M-key interface with PCIe protocol for compact installs

C&N 10G M.2 SFP+ Network Card

This network interface card adds a single 10 Gbps SFP+ port through an M.2 M-key slot using PCIe 2.0 x4 lanes. The Intel 82599EN controller handles 10 Gigabit and 1 Gigabit Ethernet traffic with hardware offloads for TCP/IP, iSCSI and FCoE. Virtualization features include SR-IOV, VMDq and IEEE 1588v2 timestamping. A low-profile bracket and SFF-8087 cable are included for installation flexibility.

Suitable for servers and workstations with a free

Builders who need 10 GbE over fiber or direct-attach copper without occupying a full-size PCIe slot will benefit from this adapter. It supports PXE and UEFI boot for diskless deployments. Systems that only provide an M.2 SATA interface cannot use this card because the M.2 SATA protocol is not supported. Buyers requiring multiple ports or a standard PCIe bracket form factor should consider other options.

M.2 M-key PCIe 2.0 x4 interface decides

The card plugs into an M.2 M-key connector that carries four PCIe 2.0 lanes. If the motherboard or riser routes only SATA signals to that M.2 socket the adapter will not function. Verify the slot is wired for PCIe before purchase.

Highlights

  • 10 Gbps throughput with Intel 82599EN controller
  • Single SFP+ port accepts fibre, DAC or AOC modules
  • PCIe 2.0 x4 lane fits x4, x8 and x16 slots
  • Broad OS support from Windows 7 to Server 2022 and Linux
  • M.2 M-key interface with PCIe protocol for compact installs

Specifications

BrandULANSeN
Speed10 gigabits_per_second
FeaturesDesktop

Questions about this item

Will the M.2 M-key PCIe 2.0 x4 slot on my older motherboard run this Intel 82599 card at full 10 Gbps?

Yes, the card uses a PCIe 2.0 x4 interface and is backward-compatible with PCIe x4, x8 and x16 slots, so an older M.2 M-key slot running PCIe 2.0 will deliver the full 10 Gbps link speed.

How can I verify the Intel 82599 controller is operating at 10 Gbps after installation?

Check the link status in the OS network adapter settings or the Intel PROSet utility; it should report a 10 Gbps full-duplex connection and show active SFP+ module details when a transceiver or DAC is inserted.

Does the box include an SFP+ transceiver or DAC, or do I need to buy one separately?

The package contains the network card, an SFF-8087 cable and a low-profile bracket; an SFP+ module, direct-attach cable or active optical cable must be purchased separately to complete the 10 GbE link.
