Black rectangular metal chassis with front panel HDMI ports and rear connections, rack-mountable video wall processor

BZBGEAR

BZBGEAR BG-UHD-VW29 4K UHD HDMI 2.0 3×3 Video Wall Processor

SKU CH-1133-JXKKR

Routes two HDMI sources across nine displays at 3840×2160@60 Hz with bezel compensation, 180° rotation and IP/RS-232 control

  • Type4K UHD HDMI 2.0 3×3 Video Wall Processor
  • Resolution SupportSupport multi-resolution up to 3840x2160@60Hz video output f
  • Power Supply70W max. 110-220 VAC
  • DimensionsL430 x W220 x H44 mm
  • Weight5kg
  • 4K 60 Hz clarity on every screen
  • HDMI 2.0 and HDCP 2.2 compliant for protected content
  • Two HDMI inputs with loop-out for flexible routing
  • 180 ° rotation plus dual-mode bezel compensation
  • Control via IP, RS-232, CEC or PC software

What this video wall processor does

The BZBGEAR BG-UHD-VW29 is a 4K UHD HDMI 2.0 3×3 video wall processor built for professional AV installations. It drives up to nine displays from two HDMI sources, supporting multi-resolution output up to 3840x2160@60Hz. Integrators and venue operators use it for digital signage, control rooms and live events where a single large canvas is required.

Installation notes and common pitfalls

The unit measures L430 x W220 x H44 mm and weighs 5kg, so rack ears or a shelf with adequate depth are needed. It accepts 110-220 VAC and draws 70W max. Control is via PC software, webGUI, RS-232, TCP/IP or HDMI CEC; a frequent issue is forgetting to match the RS-232 baud rate (often 232 in documentation) or leaving CEC disabled on the source, which prevents automatic switching.

Capacity, headroom and limits

Two HDMI inputs and two loop outs feed nine scaled HDMI outputs, each configurable for brightness, contrast, saturation, sharpness and 180° rotation. Dual-mode bezel compensation aligns content across the 3×3 grid. HDCP 2.2 compliance protects premium 4K@60Hz sources. Audio de-embedding provides 3.5mm and balanced analog outputs. The nine-output limit means larger walls need additional processors.

Highlights

  • 4K 60 Hz clarity on every screen
  • HDMI 2.0 and HDCP 2.2 compliant for protected content
  • Two HDMI inputs with loop-out for flexible routing
  • 180 ° rotation plus dual-mode bezel compensation
  • Control via IP, RS-232, CEC or PC software

Specifications

BrandBZBGEAR
ModelBG-UHD-VW29
Type4K UHD HDMI 2.0 3×3 Video Wall Processor
Resolution SupportSupport multi-resolution up to 3840x2160@60Hz video output for video wall
Power Supply70W max. 110-220 VAC
DimensionsL430 x W220 x H44 mm
Weight5kg

Questions about this item

How do I verify the BG-UHD-VW29 is outputting 3840x2160@60Hz to all nine displays after setup?

Use the PC software or webGUI to confirm each of the nine HDMI scaling outputs reports 3840x2160@60Hz, check that HDCP 2.2 status shows active on every output, and verify the loop-out ports pass the same resolution.

What comes in the box with the BG-UHD-VW29 and what must I source separately?

The unit includes the 3×3 video wall processor with 2 HDMI inputs, 2 HDMI loop outs, 9 HDMI outputs, 3.5 mm and balanced analog audio outputs, RS-232 and TCP/IP control ports, and a 110-220 VAC power supply; HDMI cables and displays are not included.

Which version of the BG-UHD-VW29 should I choose for a 3×3 wall with bezel compensation and 180° rotation?

The single model BG-UHD-VW29 supports 3×3 configurations, dual-mode bezel compensation, 180° display rotation, and per-output brightness, contrast, saturation, and sharpness adjustment — no other versions are offered.
