Compact silver metal box with HDMI ports, RJ45 jack, 3.5mm audio input and power socket

BZBGEAR

BZBGEAR BG-HAVS 1080p H.264/265 HDMI Streaming Encoder

SKU CH-CMJ9-JP2SR

HDMI encoder streams 1080p60 H.264/265 directly to platforms with loop-out, 3.5 mm audio in, and logo overlay

  • Audio3.5mm (line in) x 1
  • Video InputHDMI Type A x 1
  • Video OutputHDMI Type A x 1
  • Other ConnectorRJ-45 x 1 (100/1000Mbps self-adaptive Ethernet) STANDARDS
  • Power Consumption5W
  • Dimensions104×75.5×24.5mm
  • Stream directly to platforms without a computer
  • Encode at up to 1080p@60fps using H.264/H.265
  • Loop HDMI output to a local monitor while streaming
  • Embed stereo audio via 3.5 mm line input
  • Brand streams with built-in image and text overlays

Single-Channel 1080p Streaming Encoder

The BG-HAVS encodes an HDMI source into H.264 or H.265 IP streams for direct broadcast to platforms such as YouTube, Twitch or Facebook. It also records to an NVR or PC without requiring a host computer. A 3.5 mm analogue input embeds stereo audio into the outgoing stream.

Gigabit Ethernet and Sub-Stream Limits

The RJ-45 port negotiates at 100 or 1000 Mbps and carries both the main and a simultaneous sub-stream. The main stream reaches 1920×1080 at 60 fps while the sub-stream tops out at 720p, restricting the second feed to lower-bandwidth destinations. Only one HDMI input is available, so multi-camera switching must be handled upstream.

Resolution Headroom and Encoding Overhead

Supported encoding resolutions range from 1920×1080 down to 640×360, covering full HD through common streaming ladder steps. H.265 compression reduces bitrate compared with H.264 at equivalent quality, but the single-channel design caps total throughput at the encoder’s 5 W power envelope. Builders needing 4K input or multi-channel mixing will need a different appliance.

Highlights

  • Stream directly to platforms without a computer
  • Encode at up to 1080p@60fps using H.264/H.265
  • Loop HDMI output to a local monitor while streaming
  • Embed stereo audio via 3.5 mm line input
  • Brand streams with built-in image and text overlays

Specifications

BrandBZBGEAR
ModelBG-HAVS
Audio3.5mm (line in) x 1
Video InputHDMI Type A x 1
Video OutputHDMI Type A x 1
Other ConnectorRJ-45 x 1 (100/1000Mbps self-adaptive Ethernet) STANDARDS
Power Consumption5W
Dimensions104×75.5×24.5mm
WeightNet weight: 310g, Gross weight: 690g
Video EncodingEncoding Resolution: 1920×1080, 1680×1056, 1280×720, 1024×576, 960×540, 850×480, 720×576, 720×540, 720×480, 720×404, 720×400, 704×576, 640×480, 640×360

Questions about this item

Which resolution preset should I pick for a 1080p stream?

Choose 1920×1080 for full HD at up to 60 fps; lower presets such as 1280×720 or 640×360 are available if bandwidth is limited.

What does the 1080p@60Hz rating mean when the encoder is live?

The device can ingest a 1080p signal at 60 frames per second and encode it in H.264 or H.265 for simultaneous streaming and local loop-out monitoring.

How fast is the RJ-45 port and what does that cap?

The self-adaptive Ethernet port negotiates at 100 or 1000 Mbps, so the maximum outbound bitrate is limited to the negotiated link speed.
