Silver rackmount audio processor with front display and rotary controls

BZBGEAR

BZBGEAR BG-A1616MD 16x16 Digital Audio Processor 12-Channel Dante

SKU CH-HC7D-RYTW7

A 16x16 digital audio processor with 12-channel Dante I/O and comprehensive DSP modules

  • TypeOthers
  • 16x16 matrix routes any input to any output
  • 12 microphone or line inputs with 12 line outputs
  • Two Dante ports enable low-latency network audio
  • Adaptive echo cancellation and noise suppression clear speech
  • RS-232 serial control integrates with Windows 7 and 10

16x16 Digital Audio Processor

The BZBGEAR BG-A1616MD is a 16x16 balanced digital audio processor designed for professional installations. It provides 12-channel microphone and line-level inputs alongside 12-channel line outputs. The unit is built for video conferencing, distance learning, and telemedicine environments where clear, managed audio is essential.

12-Channel Mic Line and Dante I/O

The processor handles 12 channels of mic and line input with adaptive echo cancellation, noise suppression, and automatic gain control. An auto mixer prioritises active microphones during multi-mic use. Four channels of Dante input and output connect via two Dante ports for low-latency network audio. DSP modules including expander, equaliser, compressor, limiter, filters, and delay provide detailed signal shaping.

RS-232 and Windows Control Limits

Control is managed through RS-232 serial commands for integration with third-party systems. Software compatibility is confirmed for Windows 7 and Windows 10 platforms only. The fixed 16x16 matrix architecture means input and output counts cannot be expanded beyond the built-in 12 analogue and 4 Dante channels. Buyers needing more analogue I/O or different OS support should consider other solutions.

Highlights

  • 16x16 matrix routes any input to any output
  • 12 microphone or line inputs with 12 line outputs
  • Two Dante ports enable low-latency network audio
  • Adaptive echo cancellation and noise suppression clear speech
  • RS-232 serial control integrates with Windows 7 and 10

Specifications

TypeOthers

Questions about this item

Will the 12-channel Dante I/O integrate with my existing Dante devices?

The unit provides two Dante ports carrying 12 channels of low-latency audio that connect directly to other Dante-enabled gear on the same network.

How can I verify the DSP modules are processing signals correctly after installation?

Use the Windows 7 or 10 control software to monitor real-time levels on the 16×16 matrix and confirm Expander, EQ, Compressor, AGC, Limiter, HPF, LPF and Delay activity on each channel.

Does the box include the RS-232 cable for serial control or must I source it separately?

The processor ships with the 16×16 matrix, dual Dante ports and 12-channel mic/line I/O built in; an RS-232 cable for serial commands is not included and must be purchased separately.
