Copper compression lug, one hole, straight tongue, brown finish

Burndy

Burndy YA2CL4BOX One-Hole Compression Lug 2 AWG 3/8 in Stud

SKU CH-PTWJ-NQ3M4

Copper compression lug for 2 AWG wire with 3/8 in stud, brown colour code, die code 10, 0.61 in tongue, inspection hole and 35 kV rating

  • TypeElectrical Connectors
  • Copper construction handles 35 kV AC
  • Die code 10 matches standard tooling
  • Inspection hole confirms full crimp engagement
  • Rated to 194 °F for high-temp environments
  • 61 in tongue fits 3/8 in stud cleanly

Burndy 2 AWG Copper Compression Lug

This Burndy YA2CL4BOX compression lug connects 2 AWG stranded copper conductors using a standard crimp tool. The barrel carries a brown colour code and die code 10 for quick identification on site. An inspection hole lets the installer verify full conductor insertion before energising the circuit. The straight tongue mounts on a 3/8 inch stud with a tongue width of .61 inches.

Installers needing a single-hole 2 AWG copper lug

The lug is rated for 35 kV AC and a maximum operating temperature of 194 degrees Fahrenheit, making it suitable for medium-voltage panel work and heavy-duty automotive grounding. It accepts only 2 AWG stranded copper wire; solid conductors, aluminium wire or other gauges require a different connector. Builders needing multi-hole pads, angled tongues or splice barrels will not find those features here.

2 AWG stranded copper only

The connector is engineered for a single wire size: 2 AWG stranded copper, minimum and maximum. No other gauge or conductor material fits the barrel, so the wire size on the job must match exactly. Crimp termination with a die code 10 tool completes the connection.

Highlights

  • Copper construction handles 35 kV AC
  • Die code 10 matches standard tooling
  • Inspection hole confirms full crimp engagement
  • Rated to 194 °F for high-temp environments
  • 61 in tongue fits 3/8 in stud cleanly

Specifications

BrandBURNDY
TypeElectrical Connectors

Questions about this item

Does the lug get hot when it carries full rated current all day?

The copper body is rated for 194 Degrees F maximum operating temperature under load.

What crimp tool and die do I need to install this 2 AWG lug?

Use a die coded 10 that matches the brown colour code on the barrel.

Will this straight-tongue lug clear the terminals on my existing bus bar?

The tongue is 0.61 in wide with a 3/8 in stud hole and no angle offset.
