Aluminium two-hole lug, slotted head, 4.69 in long

Burndy

Burndy Two Conductor Lugs 2AWG 4.69In

SKU CH-F9ZF-W94SE

Two-hole aluminium lug accepts two 2 AWG stranded copper conductors at 600 V with 1.75 in spacing and 194 °F rating

  • TypeCommercial
  • Two conductors per lug for efficient parallel terminations
  • Accepts aluminium and copper conductors from 2 AWG to 600 kcmil
  • Rated 600 V and 194 °F for demanding commercial power circuits
  • Dual 0.56 in holes on 1.75 in centres match standard stud patterns
  • Compact 4.69 in length with 0.44 in tongue thickness fits tight panels

Burndy 2 AWG Dual Lug Connector

This Burndy mechanical lug accepts stranded copper or aluminium conductors from 2 AWG up to 600 kcmil. The aluminium body carries two conductors and two terminations, rated for 600 V and a maximum operating temperature of 194 degrees F. Two mounting holes spaced 1.75 in apart suit a 1/2 in stud.

Installers needing a two-hole aluminium lug

The connector suits panel builders and maintenance teams joining large-gauge copper or aluminium cable to busbar or equipment pads. It does not fit single-hole lug patterns, nor will it accept solid conductors or wire smaller than 2 AWG. Buyers needing a copper body, a different hole spacing or a single-conductor entry should look at alternative lug designs.

600 V aluminium lug with 1.75 in hole spacing

The critical specification is the 1.75 in centre-to-centre hole spacing matched to a 1/2 in stud, which determines whether the lug aligns with existing busbar or equipment drilling. The 600 V rating and 194 degrees F temperature limit define the electrical and thermal envelope for the connection.

Highlights

  • Two conductors per lug for efficient parallel terminations
  • Accepts aluminium and copper conductors from 2 AWG to 600 kcmil
  • Rated 600 V and 194 °F for demanding commercial power circuits
  • Dual 0.56 in holes on 1.75 in centres match standard stud patterns
  • Compact 4.69 in length with 0.44 in tongue thickness fits tight panels

Specifications

BrandBurndy
TypeCommercial

Questions about this item

How hot can the lug body reach under full 600 V load?

The aluminium body is rated for a maximum operating temperature of 194 degrees F, so it stays within that limit even at the full 600 V rating.

What crimp tool and die size are needed for the 2 AWG stranded copper conductors?

Use a hydraulic crimper with a die matched to 2 AWG stranded copper; the lug accepts wire from 2 AWG up to 600 kcmil and has two terminations.

Will the 1.75 in hole spacing line up with the 1/2 in studs on my existing bus bar?

Yes — the lug provides two holes at 0.56 in diameter spaced 1.75 in apart, matching standard 1/2 in stud patterns.
