Aluminium T-shaped two-port connector, 1.56 in, clear plastisol insulation

Burndy

Burndy Multi Tap Connector 14AWG 1.56In 2 Ports T

SKU CH-6T14-XWYCH

A two-port T-style multitap connector accepting stranded copper from 14 AWG to 2/0 AWG at up to 600 V and 194 °F

  • Type2 Ports, Double Sided Entry, T
  • 2-port double-sided entry simplifies wire routing
  • Aluminium body accepts copper and aluminium conductors
  • Plastisol insulation rated to 194 °F for heat resistance
  • UL 94 V-0 flammability rating meets safety standards
  • 600 V maximum voltage handles standard circuits

Electrical Wire Connector

This Burndy Multi Tap Connector joins two conductors in a T configuration with double-sided entry. It accepts stranded copper or aluminium wires from 14 AWG up to 2/0 AWG. The body is unplated aluminium insulated with Plastisol and rated for 600 V.

Indoor Panel Builders

The connector suits installers terminating two cables in junction boxes or control panels where a compact T joint is required. It is not intended for applications needing more than two ports or for conductors larger than 2/0 AWG.

600 Volt Rating

The maximum operating voltage is 600 V and the insulation carries a UL 94 V-0 flammability rating. The assembly operates up to 194 degrees F and uses a 3/16 in hex key for termination.

Highlights

  • 2-port double-sided entry simplifies wire routing
  • Aluminium body accepts copper and aluminium conductors
  • Plastisol insulation rated to 194 °F for heat resistance
  • UL 94 V-0 flammability rating meets safety standards
  • 600 V maximum voltage handles standard circuits

Specifications

BrandBurndy
Type2 Ports, Double Sided Entry, T

Questions about this item

What size hex key do I need to tighten the set screws on this connector?

A 3/16 inch hex key fits the screw heads on the two-port body.

What is the largest wire gauge this connector accepts for continuous use?

The maximum stranded copper size listed is 2/0 AWG for the two ports.

How hot does the insulation get when the connector carries full load all day?

The plastisol insulation is rated for a maximum operating temperature of 194 degrees Fahrenheit.
