Aluminium T-shaped multitap connector, two ports, clear plastisol insulation

Burndy

Burndy Multi Tap Connector 10AWG 2.64In 2 Port T

SKU CH-5CRF-EN0EX

A 2.64-inch aluminium multi-tap connector with two ports accepting stranded copper wire from 10 AWG up to 250 kcmil, rated for 600 V and 194 °F

  • Length2.700
  • Type2 Ports, Double Sided Entry, T
  • Two ports allow parallel wire connections
  • Double-sided entry simplifies cable routing
  • T-shaped body suits branch circuit layouts
  • UL 94 V-0 rating meets flammability standards
  • Rated 600 volts for industrial power circuits

Burndy Multi Tap Connector 10AWG

The Burndy Multi Tap Connector is a two-port T-shaped connector designed for joining stranded copper or aluminium conductors. It accepts wire sizes from 10 AWG up to 250 kcmil and is rated for 600 volts maximum. Electrical contractors and automotive technicians use it for branching power distribution in panels or vehicle wiring harnesses.

600 V aluminium connector limits

The aluminium body with plastisol insulation carries a UL 94 V-0 flammability rating and a maximum operating temperature of 194 degrees Fahrenheit. The 5/16 inch hex head secures conductors on both sides of each port for double-sided entry. Voltage and temperature ceilings restrict use to standard low-voltage circuits within the stated thermal envelope.

Hex tool install common issues

Installation requires a 5/16 inch hex driver to torque the set screws onto stripped conductors; no specialised crimp tool is needed. The clear unplated finish allows visual confirmation of wire insertion depth. Stripping length errors or insufficient torque on the hex screws are the typical causes of loose connections or overheating.

Highlights

  • Two ports allow parallel wire connections
  • Double-sided entry simplifies cable routing
  • T-shaped body suits branch circuit layouts
  • UL 94 V-0 rating meets flammability standards
  • Rated 600 volts for industrial power circuits

Specifications

BrandBurndy
Length2.700
Type2 Ports, Double Sided Entry, T

Questions about this item

Should I pick the 10 AWG version or the 250 kcmil capacity for my wiring job?

The connector accepts stranded copper from 10 AWG up to 250 kcmil, so choose the wire size your circuit requires; the connector itself covers the whole range.

What does the 600 V rating mean once the connector is installed in a panel?

It certifies the connector for circuits up to 600 volts, so it can be used in standard low-voltage distribution without exceeding its insulation limit.

How does the UL 94 V-0 rating affect the Plastisol insulation in practice?

The V-0 rating means the insulation self-extinguishes within ten seconds after flame exposure, helping the assembly meet fire-safety requirements.
