Long copper lug, two holes, straight tongue, white colour code

Burndy

Burndy Long Barrel Copper Lug 2 Hole 2-3 AWG

SKU CH-J4XJ-8JC7Q

A two-hole copper compression lug with a 3.500 in long barrel for 2–3 AWG stranded wire, rated to 35 kV and 194 °F

  • Length3.500
  • MaterialCopper
  • TypeCommercial
  • Copper construction provides high conductivity for reliable connections
  • Long barrel design ensures secure crimp termination on 2-3 AWG conductors
  • Dual 3/8 inch stud holes with 1 inch spacing allow flexible mounting options
  • UL 486A-486B listed and CSA certified for code-compliant installations
  • Rated up to 35 kV and 194 degrees F for demanding commercial applications

Copper Compression Lug 2 Hole 3/8 in

This Burndy long-barrel compression lug connects 2 to 3 AWG stranded copper conductors to a 3/8 inch stud. The straight tongue measures 0.58 inches wide with a 1 inch hole centre spacing. It is UL listed and CSA certified for use up to 35 kV and 194 degrees F.

Installers needing a two-hole copper crimp terminal

Suits electricians and maintenance technicians who require a code-compliant copper lug for 2-3 AWG wire on a 3/8 inch bolt pattern. Not intended for aluminium conductors, smaller or larger wire gauges, single-hole mounting, or applications above the rated temperature and voltage limits.

Long barrel for 2-3 AWG copper wire

The extended barrel length of 3.500 inches provides additional crimp surface area for secure termination on 2 to 3 AWG stranded copper. This single dimensional attribute determines whether the lug fits the available space and meets the mechanical requirements of the connection.

Highlights

  • Copper construction provides high conductivity for reliable connections
  • Long barrel design ensures secure crimp termination on 2-3 AWG conductors
  • Dual 3/8 inch stud holes with 1 inch spacing allow flexible mounting options
  • UL 486A-486B listed and CSA certified for code-compliant installations
  • Rated up to 35 kV and 194 degrees F for demanding commercial applications

Specifications

BrandBurndy
Length3.500
MaterialCopper
TypeCommercial

Questions about this item

Does the Burndy lug come with mounting bolts or crimp dies, or do I buy them separately?

Only the copper lug is included; mounting bolts for the 3/8 in studs and the die code 9 crimp tool must be sourced separately.

The spec lists 2-3 AWG — which conductor size does this lug actually fit?

It is rated for a single stranded copper conductor of exactly 3 AWG, both minimum and maximum.

What does the 35 kV rating mean when the lug is crimped onto 3 AWG wire in a panel?

The assembly is UL 486A-486B listed and CSA certified for up to 35 kV at 194 °F maximum operating temperature.
