Bronze ground connector with two wire ports 1.5in long

Burndy

Burndy KC22J12T13 Ground Connector Bronze 1.5in

SKU CH-07WM-8NPYD

Bronze ground connector joins two 8–2 AWG solid wires with a 1/2-13 thread, UL 467 listed for direct burial

  • TypeElectrical Connectors
  • UL listed for direct burial safety
  • Leaded bronze alloy resists corrosion
  • Accepts 10 AWG to 3 AWG conductors
  • Mechanical clamp installs at 80 in-lb torque
  • 5 in overall length fits tight spaces

Ground Connector for 10–3 AWG Conductors

This Burndy KC22J12T13 connector joins grounding wires from 8 to 2 AWG solid or 10 AWG stranded to 3 AWG. The leaded bronze alloy body accepts two wires and is UL Listed for direct burial. It threads onto a 1/2-13 stud with an overall length of 1.5 inches.

Suited for Direct-Burial Grounding Jobs

Installers needing a mechanical lug for two grounding conductors in buried or exposed locations will find this part matches the UL467 listing. It is not intended for live-phase connections, data cabling or any application above its rated conductor range.

Verify Thread Size and Torque Tooling

Confirm the mounting stud is 1/2-13 and that a torque wrench capable of 80 in-lb is available. Check that the conductor insulation and strand class fall within the 10 AWG stranded to 3 AWG window before ordering.

Highlights

  • UL listed for direct burial safety
  • Leaded bronze alloy resists corrosion
  • Accepts 10 AWG to 3 AWG conductors
  • Mechanical clamp installs at 80 in-lb torque
  • 5 in overall length fits tight spaces

Specifications

BrandBURNDY
TypeElectrical Connectors

Questions about this item

What wire sizes must I already have for the KC22J12T13 to accept them?

The connector accepts grounding wire from 8 to 2 AWG solid and conductor sizes from 10 AWG stranded to 3 AWG.

Will the 1/2 In. -13 thread on this ground connector fit the existing stud on my older transformer?

Yes, the KC22J12T13 uses a standard 1/2 In. -13 thread size that matches many legacy transformer studs.

How do I verify the mechanical connection is properly tightened after installation?

Torque the hardware to 80 in-lb; the UL Listed and UL467 markings confirm the connector meets direct-burial grounding standards.
