Aluminum four-hole lug with hex socket, silver finish

Burndy

Burndy Four Conductor Lug 6AWG 4.25In

SKU CH-RPFH-S5FEV

Four-conductor lug for 6 AWG to 250 kcmil copper or aluminum wire, 600 V rated, with four 0.56 in holes on 1.75 in spacing

  • TypeCommercial
  • Connects four conductors with single lug
  • Accepts aluminum or copper stranded wire from 6 AWG to 250 kcmil
  • Four 0.56 in holes spaced 1.75 in for secure mounting
  • Hex socket head enables reliable torque application
  • Rated 600 V and 194 °F for demanding commercial use

Four-Conductor Lug for 6 AWG Wire

This Burndy mechanical connector accepts stranded copper or aluminum conductors from 6 AWG up to 250 kcmil. It provides four termination points rated for 600 volts and a maximum operating temperature of 194 degrees Fahrenheit. The aluminum body uses a hex-socket head style for secure installation.

Four Holes Spaced at 1.75 Inches

The tongue measures 3.16 inches long, 3.69 inches wide and .31 inches thick with four mounting holes of .56 inch diameter. This pattern supports a 1/2 inch stud size across all four conductors. The fixed spacing determines compatibility with specific bus bars or terminal blocks.

600 Volt Rating and 194 Degree Limit

The 600 volt maximum and 194 degree Fahrenheit temperature ceiling define the safe operating envelope for this lug. Installations exceeding either value require a different connector. Buyers needing higher voltage insulation or higher temperature tolerance must select an alternative part.

Highlights

  • Connects four conductors with single lug
  • Accepts aluminum or copper stranded wire from 6 AWG to 250 kcmil
  • Four 0.56 in holes spaced 1.75 in for secure mounting
  • Hex socket head enables reliable torque application
  • Rated 600 V and 194 °F for demanding commercial use

Specifications

BrandBurndy
TypeCommercial

Questions about this item

Will the four-hole hex-socket lug need re-torquing after thermal cycling?

The aluminium body rated for 194°F maximum operating temperature may expand and contract with load changes, so periodic re-torquing of the hex-socket terminations is recommended.

What limits continuous current before the lug overheats?

The 600 V rating and 194°F maximum operating temperature set the thermal ceiling; exceeding either risks insulation damage on the 6 AWG to 250 kcmil conductors.

How hot does the aluminium body get when all four conductors run at full load all day?

The lug is rated to a maximum operating temperature of 194°F, so the body will approach that limit under sustained full-load conditions.
