Copper terminal lug with two bolt holes, hex head, 3.19 inch length

Burndy

Burndy 3/0 AWG Copper Terminal 3.19In

SKU CH-0BVE-G9KMS

Copper terminal for 3/0-4/0 AWG stranded wire, 600 V rated, 3/8 in stud, 1 in hole spacing, 3.19 in length

  • TypeCommercial
  • Copper body conducts reliably up to 600 V
  • Hex head design allows secure mechanical tightening
  • Two-hole pattern with 1 in spacing simplifies mounting
  • Rated for 194 °F maximum operating temperature
  • Accepts stranded copper from 3/0 to 4/0 AWG

Terminal for 3/0–4/0 AWG Copper

This Burndy copper terminal accepts stranded copper conductors from 3/0 AWG up to 4/0 AWG. It provides a single termination point rated for 600 V and a maximum operating temperature of 194 Degrees F. The hex head design suits commercial electrical and industrial wiring tasks.

Verify wire gauge and stud fit

Confirm your stranded copper wire falls within the 3/0 to 4/0 AWG range before ordering. The terminal mounts on a 3/8 in stud and requires two holes of 0.41 in diameter spaced 1 in apart. Tongue dimensions are 2 in long, 1 in wide and 0.25 in thick.

Replaces worn single-hole lugs

This two-hole terminal upgrades from single-hole lugs when bolt-hole spacing of 1 in matches the bus bar or panel. The jump is worth it when vibration resistance and secure mounting on 3/8 in hardware are required for 600 V copper circuits.

Highlights

  • Copper body conducts reliably up to 600 V
  • Hex head design allows secure mechanical tightening
  • Two-hole pattern with 1 in spacing simplifies mounting
  • Rated for 194 °F maximum operating temperature
  • Accepts stranded copper from 3/0 to 4/0 AWG

Specifications

BrandBurndy
TypeCommercial
