Rectangular black desktop NAS with two drive bays and front status LEDs

Buffalo Technology

Buffalo Technology TS3230DN1602 2-Bay NAS 16TB

SKU CH-K2SQ-XFM9P MPN TS3230DN1602

A 2-bay desktop NAS with 16 TB of pre-installed storage, a quad-core 2.0 GHz processor, 2.5 GbE and 1 GbE ports, and RAID 0, 1 and JBOD support

  • TypeDesktop NAS
  • StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  • Ports1 x 1GbE
  • Port RJ-451 x 2.5GbE + 1 x 1GbE
  • Port USB2 x USB3.0
  • HDD Interface2 x SATA (2 x Bay)

Included HDD Capacity 16TB (2 x 8TB)

  • Ready-to-use 16TB storage with two 8TB drives included
  • Quad-core 2.0GHz processor handles demanding workloads
  • 5GbE and 1GbE ports for flexible network speed
  • RAID 0, 1 and JBOD protect or maximise capacity
  • Two USB 3.0 ports add external backup or expansion

TeraStation 3030 16TB desktop NAS

The Buffalo TeraStation 3030 ships as a 2-bay desktop NAS with 16TB of storage pre-installed across two 8TB drives. A quad-core Annapurna Labs Alpine AL-524 processor running at 2.0GHz and 2GB of DDR4 memory handle file serving and RAID management. The unit supports RAID 0, RAID 1 and JBOD configurations for performance or redundancy. It is aimed at small offices and home users who need a ready-to-use network storage appliance.

Dual Ethernet ports and USB 3.0 expansion

The rear panel provides one 2.5GbE RJ-45 port and one 1GbE RJ-45 port for link aggregation or separate network segments. Two USB 3.0 ports allow attachment of external drives or a UPS for safe shutdown. Drive bays accept SATA drives and are keyed with the supplied front-panel key for physical security. LEDs show power, drive activity and link status at a glance. The chassis measures 9.1 x 6.7 x 6.7 inches and weighs 9.5 lbs.

Quick setup guide and accessories included

The package contains a quick setup guide, a Cat5e Ethernet cable, an AC power cable and the front-panel key. The warranty statement is also supplied in the box. No additional drive brackets or mounting rails are required for the two pre-installed drives. The NAS operates on 100-240 VAC at 50/60Hz with a typical power draw of 33.88W. Buyers who need more than two drive bays or 10GbE connectivity will need a different platform.

Highlights

  • Ready-to-use 16TB storage with two 8TB drives included
  • Quad-core 2.0GHz processor handles demanding workloads
  • 5GbE and 1GbE ports for flexible network speed
  • RAID 0, 1 and JBOD protect or maximise capacity
  • Two USB 3.0 ports add external backup or expansion

Specifications

BrandBUFFALO
SeriesTeraStation 3030
ModelTS3230DN1602
Part NumberTS3230DN1602
TypeDesktop NAS
StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Ports1 x 1GbE
Port RJ-451 x 2.5GbE + 1 x 1GbE
Port USB2 x USB3.0
HDD Interface2 x SATA (2 x Bay)
Form Factor2-Bay
ProcessorAnnapurna Labs Alpine Processor AL-524 2.0GHz Quad-core
Installed Memory2GB DDR4
Included HDD Capacity16TB (2 x 8TB)
RAIDRAID 0, 1 and JBOD
Drive CompatibilityOP-HD8.0N
Supported ProtocolsTCP/IP
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption33.88W
Temperature0°C - 40 °C
Humidity10-80% Non-condensing
UsageHigh read/write performance with RAID
Dimensions9.1 x 6.7 x 6.7 in
Weight9.5 lbs.
Package ContentsTeraStation, Quick Setup Guide, 5e Ethernet Cable, AC Cable, Front Panel Key, and Warranty Statement
Shipping weight5.72 kg
Package size358 × 320 × 310 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is the maximum wired network speed the TS3230DN1602 can reach on its 2.5GbE port?

The 2.5GbE RJ‑45 port caps practical throughput at 2.5 Gbps, while the second RJ‑45 port is limited to 1 Gbps.

What physical space and drive format does the 2‑Bay chassis require?

The unit measures 9.1 × 6.7 × 6.7 in and accepts two 3.5‑inch SATA drives in its internal bays.

How do you install replacement drives in the TS3230DN1602, and what step is often missed?

Unlock the front panel with the included key, slide each drive into a bay until it clicks, then initialize the RAID array in the web UI — skipping the RAID setup leaves the drives unprotected.
