Black waterproof USB Type-B 90-degree flush-mount cable with rubber cover and dust cap, .3m length

BUCIER

BUCIER USB 2.0 Type-B 90° Waterproof Flush Mount Cable 0.3M

SKU CH-T8R4-99DY8

A waterproof USB 2.0 Type-B extension cable with a 90-degree flush-mount design for dashboard installation in vehicles and boats

  • TypeUSB
  • Connector TypeUSB Type B
  • ColorBlack
  • Cable LengthM
  • LengthM
  • Connector Number4
  • Waterproof panel mount shields connections from rain
  • 90° flush design fits tight dashboard spaces
  • USB 2.0 transfers data at 480 Mbps
  • Tool-free install uses 14×15 mm cutout
  • 30 cm cable reaches nearby devices cleanly

Waterproof USB 2.0 Type-B Cable

This 0.3 metre cable has a male Type-B plug on one end and a female Type-B port on the other. The 90-degree downward angle suits tight dashboard cut-outs in cars, trucks, boats or motorcycles. A rubber cover and flush-mount design keep the connection dry when the panel is exposed to rain or spray. Builders who need a longer reach or a different connector orientation should look elsewhere.

Flush-mount panel integration

The cable installs through a 14 by 15 millimetre hole, secured with the supplied fixing ring, washers and rubber pad. No screws or tools are required. The short length frees up space behind the dash and keeps the ECU or printer interface hidden. Installations that demand a bulkhead feed-through larger than the specified cut-out cannot use this kit.

Speed and compatibility headroom

USB 2.0 signalling runs at 480 megabits per second and falls back to 12 megabits per second for USB 1.1 or 1.5 megabits per second for USB 1.0 devices. The 28 AWG data pair and 24 AWG power conductors handle standard printer, scanner or data-transfer loads. Systems that require USB 3.0 bandwidth or higher power delivery exceed what this cable can provide.

Highlights

  • Waterproof panel mount shields connections from rain
  • 90° flush design fits tight dashboard spaces
  • USB 2.0 transfers data at 480 Mbps
  • Tool-free install uses 14×15 mm cutout
  • 30 cm cable reaches nearby devices cleanly

Specifications

BrandSinLoon
TypeUSB
Connector TypeUSB Type B
ColorBlack
Cable LengthM
LengthM
Connector Number4
Connector DetailUSB Type B
Terminal GenderMale-to-Female
Speed0.48 gigabits_per_second
Constructionrubber
FeaturesWaterproof

Questions about this item

How long is the cable once both connectors are fitted?

The cable measures 30 cm from end to end including both connectors.

How much heat does the cable generate during continuous data transfer?

As a passive copper cable it produces no measurable heat under normal USB 2.0 loads.

What size panel cut-out is required for the flush mount?

Cut a hole approximately 24.7 mm by 24.7 mm by 53 mm deep on the mounting surface.
