Brown toggle combination switch with pilot light, flush mount, single gang

Bryant

Bryant RC109 Combination Switch 15 A 120V Brown

SKU CH-MW4B-A1DEV

A combination switch and pilot light rated 15 A at 120 V AC with a brown toggle and grounded screw terminals

  • TypeCombination Devices
  • Length4.400
  • ColorBrown
  • Weight0.15
  • Single-pole toggle controls 15 A at 120 V
  • Built-in pilot light shows circuit status
  • Brown flush-mount design fits standard wall boxes
  • UL-listed construction with grounded screw terminals
  • Includes mounting hardware for quick installation

Combination Switch and Pilot Light

The Bryant RC109 combines a single-pole toggle switch with an integrated pilot light in a brown flush-mount housing. Rated for 15 A at 120 V AC, it fits a standard one-gang box with 3.27 in mounting centres. Side-entry screw terminals and included mounting hardware support a straightforward installation. UL Listed for safety compliance.

For lighting circuits needing a status indicator

Suits residential or light-commercial projects where a visible confirmation that the load is powered is required. The single-pole action controls one circuit from one location. Installers needing three-way or four-way control, a receptacle outlet, or a higher amperage rating will need a different device configuration.

15 A 120 V single-pole rating

This current and voltage rating determines whether the switch can carry the connected load safely. Verify the circuit breaker and wire gauge match the 15 A specification before fitting the unit. The NEMA 5-15R configuration reference confirms compatibility with standard North American 120 V wiring practices.

Highlights

  • Single-pole toggle controls 15 A at 120 V
  • Built-in pilot light shows circuit status
  • Brown flush-mount design fits standard wall boxes
  • UL-listed construction with grounded screw terminals
  • Includes mounting hardware for quick installation

Specifications

BrandBRYANT
TypeCombination Devices
Length4.400
ColorBrown
Weight0.15

Questions about this item

Will the 15 A 120 V toggle switch fit in a standard single-gang box with 3.27 in mounting centres?

Yes, the combination device is designed for a single-gang flush mount with 3.27 in centre-to-centre holes and includes mounting hardware.

How can I confirm the pilot light is operating correctly after installation?

The built-in pilot light illuminates when the single-pole toggle is in the ON position, giving immediate visual confirmation.

Does the box contain wire connectors or only the switch and mounting screws?

The package includes the combination switch with pilot light and mounting hardware; wire connectors are not supplied.
