Bryant 9903W 20 A 3-Way Rocker Wall Switch
A white rocker wall switch rated 20 A at 120/277 V AC with 3-way maintained action, 2 hp motor rating, screw terminals and a stainless-steel spring wire, standing 1.7 in tall
- Controls two locations with 3-way rocker action
- Handles 20 A at 120/277 V AC for heavy loads
- Rated 2 hp for motor-starting duty
- Installs quickly via back and side screw terminals
- Compact 1.7 in height fits standard boxes
Industrial-grade 20 A rocker switch
The Bryant 9903W is a single-pole 3-way wall switch rated for 20 A at 120/277 V AC with a 2 hp motor load. It uses a maintained rocker action and screw terminals that accept back or side wiring for secure connections.
Suited for commercial
This switch fits panels that require a 20 A 3-way rocker with UL/CSA listing and a stainless-steel spring wire mechanism. Installers needing a lower amperage, a different switching function or a locking style should select another model.
Mounts in standard wall boxes with 1.7 in.
The screw-terminal design works with solid or stranded conductors and the white rocker provides clear visual status. No special tools or additional components are required beyond the box and wiring supplied by the installer.
Highlights
- Controls two locations with 3-way rocker action
- Handles 20 A at 120/277 V AC for heavy loads
- Rated 2 hp for motor-starting duty
- Installs quickly via back and side screw terminals
- Compact 1.7 in height fits standard boxes
Specifications
| Brand | ZORO SELECT |
|---|
Questions about this item
Does the Bryant 9903W need a neutral wire in the box for the 3-way circuit to work?
The switch uses screw terminals for back or side wiring and carries the travellers and line/load conductors; a neutral is only required if the specific 3-way wiring method calls for it.
Will the 20 A rocker fit in the same wall box as the older toggle switch I am replacing?
The device is a standard single-gang switch with 1.7 in overall height and screw-terminal connections, so it mounts in a typical wall box used for toggle switches.
How can I confirm the switch is operating correctly after installation?
Toggle the rocker from each 3-way location; the connected load should turn on and off from both positions without sticking, indicating the maintained contacts are functioning.
