Small square black mini PC with VESA mount and multiple ports

BRENUC

BRENUC BREC barebone mini PC Core Ultra 5 225H 14-core 128GB DDR5 Arc 130T

SKU CH-Z1QT-CQY9Z

Barebone mini PC with a 14-core Intel Core Ultra 5 225H processor, dual-channel DDR5 support up to 128GB, Intel Arc 130T graphics driving four 4K displays, Wi-Fi 6E and Bluetooth 5.3

  • AI FeaturesAI Ready
  • CPU TypeIntel Core Ultra 5 225H
  • CPU Cores14
  • Memory installedNo Memory
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 5600

Option 32GB RAM / 1TB SSD

  • 14-core Intel Core Ultra 5 225H processor delivers AI-ready performance for multitasking
  • Supports up to 128GB dual-channel DDR5 5600MHz memory for demanding workloads
  • Intel Arc 130T graphics drives four independent 4K@60Hz displays via HDMI and USB-C
  • Wi-Fi 6E and Bluetooth 5.3 provide fast, stable wireless connectivity on the 6GHz band
  • 5Gbps LAN plus four USB 3.2 Gen2 ports enable high-speed wired networking and peripherals

BRENUC BREC barebone mini PC

The BRENUC BREC is a compact barebone mini PC built around an Intel Core Ultra 5 225H processor with 14 cores and a maximum turbo frequency of 4.9 GHz. It ships without memory or storage so integrators can populate the two 288-pin DDR5 5600 SODIMM slots and the M.2 2280 PCIe 4.0 x4 NVMe socket. A 120 W 19 V power adapter and VESA mount are included.

Suits builders who need four 4K displays

This unit targets system builders creating digital-signage players, multi-monitor workstations or compact AI-ready appliances that demand quad 4K@60 Hz output via two HDMI 2.1 and two full-function Type-C ports. It is not for buyers who want a complete system with RAM and SSD pre-installed, nor for those requiring a second 2.5 GbE port or additional USB 2.0 headers beyond the single 2.5 GbE RJ45 and four USB 3.2 Gen2 Type-A ports provided.

Deciding spec: 128 GB DDR5 5600 dual-channel ceiling

The defining limit is the 128 GB maximum capacity across two DDR5 5600 SODIMM slots running in dual-channel mode. If your workload fits within that ceiling the platform delivers the memory bandwidth needed for the integrated Arc 130T graphics and AI acceleration; if you need more memory you must select a different barebone.

Highlights

  • 14-core Intel Core Ultra 5 225H processor delivers AI-ready performance for multitasking
  • Supports up to 128GB dual-channel DDR5 5600MHz memory for demanding workloads
  • Intel Arc 130T graphics drives four independent 4K@60Hz displays via HDMI and USB-C
  • Wi-Fi 6E and Bluetooth 5.3 provide fast, stable wireless connectivity on the 6GHz band
  • 5Gbps LAN plus four USB 3.2 Gen2 ports enable high-speed wired networking and peripherals

Specifications

BrandBRENUC
SeriesBREC
ModelIntel Core UItra 5 225H
AI FeaturesAI Ready
CPU TypeIntel Core Ultra 5 225H
CPU Cores14
Memory installedNo Memory
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 5600
Max Memory Supported128GB
Dual Channel Memory SupportedYes
Serial ATA1 x M.2 B-key PCIe Gen3 x1 22x42(SAT3.0)
M.2 Slot1 x M.2 2280 PCIe 4.0 X4 NVMe SSD
Discrete Graphic CardIntel ARC 130T Graphics
Onboard AudioIntegrated
Channel7.1 Channel
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6E
BluetoothBluetooth 5.3
Front USB2 x USB 3.2 Gen2(10Gbps) Type-A ports
Front Audio Ports3.5mm Audio Jack
Other Front Ports1 x Type-C (USB2.0)
HDMI2 x HDMI 2.1 TMDS
Thunderbolt2 x Type-C Full Function Port
Rear USB2 x USB 3.2 Gen2(10Gbps) Type-A port
RJ451 x 2.5Gb RJ45
Input19VDC /6.32A
Power Supply120W
Dimensions136 x 123 x 51mm
MaterialHigh-density plastic with metal frame
PackagingIndividual retail box packaging

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How loud or hot does the 120W power adapter and Core Ultra 5 225H run during all-day workloads?

The 120W adapter (19V, 6.32A) powers the 14-core CPU and Arc 130T graphics; sustained loads will draw near this limit so expect active fan cooling and warm exhaust.

Which DDR5 SODIMMs do I need to buy separately to reach the 128GB maximum?

Two 288-pin DDR5 5600 SODIMMs fill the two slots for dual-channel operation up to the supported 128GB total.

Can I keep my existing 2.5GbE switch and Wi-Fi 6E router with this unit?

Yes — the 2.5Gbps RJ45 port and Intel Wi-Fi 6E AX211 with Bluetooth 5.3 connect directly to those standards.
