Compact grey metal enclosure with five Ethernet ports and removable power terminal

Brainboxes

Brainboxes SW-105 5-Port Industrial Ethernet Switch

SKU CH-JNZY-YCBH9 MPN SW-105

Compact industrial switch with five galvanically isolated 10/100 Mbps ports, dual redundant power inputs accepting USB or 24 V, and an operating range of -40 °C to +80 °C

  • Switch TypeOthers
  • Weight0.35
  • Galvanic isolation on every port protects against ground loops
  • Industrial temperature range from -40 °C to +80 °C for harsh environments
  • Dual redundant power inputs accept USB or 24 V factory supply
  • Unmanaged 5-port Fast Ethernet switch requires no software configuration
  • Compact plug-in form factor measures 3.7" × 3.5" × 0.8

Industrial Ethernet switch for embedded systems

The Brainboxes SW-105 is a five-port unmanaged switch built for industrial and embedded deployments. Galvanic isolation on every port protects connected equipment from ground loops and voltage spikes. It operates across a -40 °C to +80 °C temperature range, suiting harsh environments such as factory floors or outdoor enclosures.

Fast Ethernet limits and power flexibility

Each port runs at 10/100 Mbps, so throughput tops out at Fast Ethernet speeds rather than Gigabit. The switch accepts dual redundant power inputs across a wide voltage range, including 24 V industrial supplies or USB sources. Power consumption adjusts automatically based on link status, and no software configuration is required.

Compact plug-in module with removable terminals

The unit measures 0.8 in high, 3.7 in wide and 3.5 in deep, weighing approximately 2.40 oz. A removable power terminal with numbered pins simplifies wiring and maintenance in tight cabinets. The plug-in form factor allows direct integration into custom panels or DIN-rail carriers. Manufactured in the United Kingdom, it carries RoHS and WEEE certifications.

Highlights

  • Galvanic isolation on every port protects against ground loops
  • Industrial temperature range from -40 °C to +80 °C for harsh environments
  • Dual redundant power inputs accept USB or 24 V factory supply
  • Unmanaged 5-port Fast Ethernet switch requires no software configuration
  • Compact plug-in form factor measures 3.7" × 3.5" × 0.8

Specifications

BrandBrainboxes
Switch TypeOthers
Weight0.35
Shipping weight0.16 kg
Package size152 × 127 × 51 mm

Questions about this item

Which power option suits my setup, USB or 24 V?

The switch accepts both a USB source and a 24 V supply through its dual redundant inputs, so you can power it from a PC port or the factory floor.

What does 10/100 Mbps mean for actual throughput?

Each of the five ports negotiates at 10 or 100 Mbps full duplex, giving up to 100 Mbps per connection in a real machine.

How does the Fast Ethernet interface limit my network speed?

The 10/100Base-T ports cap each link at 100 Mbps, so gigabit devices will fall back to Fast Ethernet rates.
