White rectangular wireless access point with four detachable antennas and front LED indicators

BoYata

BoYata Wireless Access Point 2 in 1 accessory

SKU CH-GCEZ-QCF8H

A dual-band wireless access point for WaveCAST systems with four detachable 5 dBi antennas, concurrent 2.4 GHz and 5 GHz operation, and WPA/WPA2 AES security

  • Four detachable 5dBi antennas extend wireless coverage
  • Dual-band 2.4GHz and 5GHz operation handles more devices
  • 1000Mbps on 2.4GHz and 2167Mbps on 5GHz deliver fast throughput
  • WPA/WPA2-PSK with AES encryption protects network traffic
  • One WAN, four LAN and one USB 3.0 port connect wired gear

Wireless Access Point for WaveCAST

The BoYata WF WR10 is a dual-band wireless access point built for WaveCAST audio distribution systems. It delivers concurrent 2.4GHz and 5GHz operation with four detachable 5dBi omni-directional antennas for broad coverage. The unit includes one WAN port, four LAN ports and a USB 3.0 port for wired expansion. It suits venues, classrooms or installations that need reliable wireless audio streaming.

Check power and network before ordering

Verify that a 12VDC 3A supply is available at the mounting location. Confirm the site can provide wired Ethernet to the WAN port for backhaul. Ensure the four LAN ports match the number of wired devices you plan to connect. The access point supports IEEE 802.11 b/g/n on 2.4GHz and IEEE 802.11 a/n/ac on 5GHz, so client devices must support those standards.

Build quality and daily connectivity

The chassis measures 9.3 by 7 by 1.65 inches and weighs 1.8 lb, with a max power draw of 35W. Detachable antennas allow repositioning or replacement for optimal signal. Gigabit WAN and LAN ports use auto MDI/MDIX for plug-and-play cabling. The USB 3.0 port adds a high-speed option for storage or peripherals. CE, FCC, RoHS, IC and RCM approvals confirm regulatory compliance.

Highlights

  • Four detachable 5dBi antennas extend wireless coverage
  • Dual-band 2.4GHz and 5GHz operation handles more devices
  • 1000Mbps on 2.4GHz and 2167Mbps on 5GHz deliver fast throughput
  • WPA/WPA2-PSK with AES encryption protects network traffic
  • One WAN, four LAN and one USB 3.0 port connect wired gear

Specifications

No published specifications for this item yet.

Questions about this item

What comes in the box with the Williams AV WF WR10 and what must I add myself?

The unit includes four detachable 5dBi omni-directional antennas and a 12 VDC 3 A power adapter. Ethernet cables for the WAN and four LAN ports are not supplied.

How do I decide between the 2.4 GHz and 5 GHz bands on this access point?

Both bands operate concurrently. The 2.4 GHz radio delivers up to 1000 Mbps under 802.11n/g/b; the 5 GHz radio reaches 2167 Mbps under 802.11n/a/ac. Choose 5 GHz for higher throughput at shorter range.

What does the 2167 Mbps 5 GHz figure mean when the WR10 is connected to my network?

That is the maximum physical-layer rate on the 5 GHz radio using 802.11ac. Real-world throughput will be lower and depends on client capability, channel width, interference and the 1 Gbps wired LAN ports.
