Silver rectangular conferencing camera with front lens and PTZ base

Boom Collaboration

Boom Collaboration BM01-1030 4K PTZ conferencing device 12x optical zoom

SKU CH-A905-SPVA4 MPN BM01-1030

Captures 4K Ultra HD video at 60fps with a Sony CMOS sensor, 12x optical zoom, and ±170° pan for large-room conferencing

  • TypeVideo Conference Device
  • Additional FeaturesUltra HD 4K @ 60fps 82° field of view PTZ with 12x optical z
  • Specification4K Ultra HD up to 3840 x 2160 @ 60fps Image sensor: Sony CMO
  • DimensionsLength: 7.13in (181mm) Width: 4.53in (115mm) Height: 5.87in
  • Weight2.54lbs (1.15kg)
  • Smooth 4K video at 60 fps for lifelike meetings
  • 12x optical zoom keeps distant participants sharp
  • Wide 82° field of view covers the whole room
  • PTZ moves ±170° pan and -30° to +90° tilt
  • Multiple outputs: USB 3.0, HDMI and LAN for flexible integration

Professional 4K conferencing camera

The Boom Collaboration BM01-1030 delivers Ultra HD 4K video at 60 frames per second using a Sony CMOS sensor. Its 82° field of view and precise pan, tilt and zoom mechanics suit meeting rooms that need flexible framing without moving the device. Remote control with ten presets lets operators recall positions instantly during a session.

Passive thermal design runs silently

No active cooling is present so the unit operates without audible fan noise in typical conference use. Power is supplied over the network connection, eliminating a separate mains adapter and keeping cabling simple. The compact chassis stays cool to the touch during extended meetings.

12x optical zoom decides fit for room size

The 12x optical zoom combined with ±170° pan and -30° to +90° tilt determines whether the camera can cover the required distance and seating layout. Rooms needing tighter long-range framing or wider angle coverage will need a different zoom specification.

Highlights

  • Smooth 4K video at 60 fps for lifelike meetings
  • 12x optical zoom keeps distant participants sharp
  • Wide 82° field of view covers the whole room
  • PTZ moves ±170° pan and -30° to +90° tilt
  • Multiple outputs: USB 3.0, HDMI and LAN for flexible integration

Specifications

BrandBoom
ModelBM01-1030
TypeVideo Conference Device
Additional FeaturesUltra HD 4K @ 60fps
82° field of view
PTZ with 12x optical zoom
USB 3.0, HDMI and LAN
Sony CMOS sensor
Remote control with 10 camera presets for quick PTZ
PTZ Control: UVC, VISCA, Pelco-D/P, Onvif via RS232, RS422/RS485, LAN, IR Remote
IP Streaming: H.265, H264, RTSP, RTMP
Specification4K Ultra HD up to 3840 x 2160 @ 60fps
Image sensor: Sony CMOS sensor (1/2.8)
View angle: 82°
PTZ parameters:
Pan: : ±170°
Tilt: -30°/+90°
Zoom: 12x optical zoom
Presets: 255 (10 with remote)
Resolution: 8.51 MP, 16:9
Focus: Auto, manual, one push
Video output: HDMI, USB 3.0
Video codec LAN: H.265, H.264
Video codec USB 3.0: H.265, H.264, MJPEG, YUY2, MJPEG, NV12
Network protocol: RTSP, RTMP, ONVIF, GB/T28181, VISCA
Audio input: Double track 3.5mm linear input
Audio output: HDMI, LAN, USB 3.0
Input voltage: DC12V ±10%
Input current: <1A
Power: <12W
DimensionsLength: 7.13in (181mm)
Width: 4.53in (115mm)
Height: 5.87in (149mm)
Cable length: 9.84ft (3m)
Weight2.54lbs (1.15kg)
Shipping weight1.36 kg
Package size254 × 203 × 178 mm

Questions about this item

How do I mount the BM01-1030 and connect it for 4K 60fps video, and what step is often missed?

Mount the 1.15 kg unit on a wall or ceiling using the 181 mm × 115 mm footprint, then use the supplied 3 m USB 3.0 cable for 3840 × 2160 @ 60 fps; the step often missed is selecting USB 3.0 in the host software instead of defaulting to USB 2.0.

What maintenance will the BM01-1030 need over time?

Clean the Sony 1/2.8 CMOS sensor glass and the 82° lens periodically with a microfibre cloth; no user-replaceable parts are specified, so mechanical PTZ wear on the ±170° pan and −30°/+90° tilt axes would require professional service.

What limit appears first when the BM01-1030 runs long meetings at 4K 60fps?

Sustained 4K 60 fps streaming over LAN or USB 3.0 can hit host CPU encoding limits or USB thermal throttling before the camera’s own 255 presets or 12× optical zoom range become a factor.
