Bare green circuit board with USB 3.0 plug and M.2 slot supporting 2230 2242 2260 2280 lengths

BONAEVER

BONAEVER M.2 SATA to USB 3.0 Card Reader 2230-2280

SKU CH-8HTA-M8WWC

Connects M.2 SATA B-key or B+M-key SSDs (2230 to 2280) to USB 3.0 at up to 5 Gbps, driver-free

  • TypeOthers
  • Converts SATA M.2 SSDs to USB 3.0 for external access
  • Supports 2230 2242 2260 2280 B key and B+M key drives
  • Theoretical 5Gbps transfer rate with USB 2.0 and 1.1 backward compatibility
  • Driver free plug and play on Windows 10 8 7 XP 2003 2000 Vista Linux and Mac OS
  • Open board design aids cooling and includes mounting screw for secure installation

BONAEVER M.2 SATA to USB 3.0 Card Reader

This adapter converts a B-key or B+M-key M.2 SATA SSD into a USB 3.0 drive. It accepts 2230, 2242, 2260 and 2280 form factors and connects directly to a computer without a cable. The bare board design aids heat dissipation and a mounting screw is included for secure installation. It is a new, plug-and-play accessory for accessing SATA-based M.2 modules.

Suits users with NGFF SATA SSDs needing USB access

Buyers who own M-key only drives or any PCIe and nVME SSDs cannot use this adapter. It also does not serve anyone requiring an enclosure for physical protection or a cable for flexible placement. The board must be trimmed at the 22 by 42 or 22 by 60 positions to fit shorter modules, a permanent change that cannot be undone.

Handles SATA SSDs up to 2280 length at USB 3.0

Theoretical throughput reaches 5Gbps and the interface is backward compatible with USB 2.0 and USB 1.1. Performance is limited by the SATA protocol of the installed drive and the USB 3.0 link. It runs out of headroom for NVMe workloads, M-key only modules or any scenario needing PCIe bandwidth or a protective shell.

Highlights

  • Converts SATA M.2 SSDs to USB 3.0 for external access
  • Supports 2230 2242 2260 2280 B key and B+M key drives
  • Theoretical 5Gbps transfer rate with USB 2.0 and 1.1 backward compatibility
  • Driver free plug and play on Windows 10 8 7 XP 2003 2000 Vista Linux and Mac OS
  • Open board design aids cooling and includes mounting screw for secure installation

Specifications

TypeOthers

Questions about this item

What type of M.2 SSD must I already own for this adapter to work?

You need an NGFF SATA SSD with a B key or B+M key in the 2230, 2242, 2260 or 2280 form factor.

Will this reader work with an older PC that only has USB 2.0 ports?

Yes, the USB 3.0 interface is backward compatible with USB 2.0 and USB 1.1 ports.

How can I confirm the adapter is functioning correctly after I install the SSD?

The drive should appear in your operating system immediately with no driver installation required.
