Small green circuit board with a 5MP camera lens, two infrared LEDs and a 15-pin ribbon cable

BONAEVER

BONAEVER 5MP Raspberry Pi Camera Module Night Vision Adjustable Focus 1080p

SKU CH-7MTJ-JN370

A 5-megapixel camera module for Raspberry Pi boards with night-vision LEDs, adjustable focus and 1080p video capture

  • TypeOthers
  • 5 MP OV5647 sensor captures 1080p video for sharp detail
  • Two infrared LEDs enable night vision recording in darkness
  • Adjustable 3.6 mm focal length lets you focus manually on any distance
  • 7 degree diagonal field of view fits wide scenes in frame
  • 15-pin FFC and 3.3 V output connect directly to all Raspberry Pi models

Raspberry Pi Camera Module

This 5 megapixel camera module uses an OV5647 sensor and connects to all Raspberry Pi revisions through a 15-pin FFC. It provides a 3.3 volt power output for attachment use and includes two fill-light LEDs for night vision recording. The adjustable focal length lets users set focus manually for different object distances.

1080p Resolution and 75.7 Degree View

The sensor captures 1080p video at its best resolution with a 75.7 degree diagonal field of view and an F1.8 aperture. Fixed-focus limitations are removed by the adjustable 3.6 millimetre lens which can be turned to suit close or distant subjects. Infrared illumination works in darkness but colour fidelity drops when the LEDs are active.

Two Fill Lights and Mounting Holes

The bundle adds two fill-light LEDs that connect to the board for low-light scenes and a 15-pin FFC for the CSI link. Four screw holes on the 25 by 24 millimetre PCB allow secure mounting inside enclosures or on brackets. No extra cables or software licences are included so users must provide their own Pi board and operating system image.

Highlights

  • 5 MP OV5647 sensor captures 1080p video for sharp detail
  • Two infrared LEDs enable night vision recording in darkness
  • Adjustable 3.6 mm focal length lets you focus manually on any distance
  • 7 degree diagonal field of view fits wide scenes in frame
  • 15-pin FFC and 3.3 V output connect directly to all Raspberry Pi models

Specifications

TypeOthers

Questions about this item

Will the 15-pin FFC cable connect to the CSI port on my Raspberry Pi 3 B+?

Yes, the 15-pin FFC fits the standard CSI connector found on the Pi 3 B+, Pi 4 Model B and earlier models listed in the compatibility details.

How can I verify the night vision is working after I attach the camera?

In a dark room the two infrared LEDs should glow faintly red and the live preview will show a clear monochrome image when the IR cut filter is disabled in software.

Which extra parts come in the package besides the camera board itself?

The box contains the camera module, two fill-light boards and a 15-pin FFC ribbon cable; no other accessories are included.
