Small green circuit board camera module with silver lens and IR-cut filter visible

BONAEVER

BONAEVER 5MP IR-Cut Camera Module Day Night 1080p30 720p60 72° FOV

SKU CH-HJ6Q-C3V4X

A 5 MP IR-cut camera module for Raspberry Pi that auto-switches day and night modes, captures 1080p at 30 fps or 720p at 60 fps, and offers a 72° adjustable field of view

  • TypeOthers
  • Automatic day-night switching avoids colour cast and keeps images clear
  • CSI interface delivers higher bandwidth for 5 MP data transfer to the processor
  • Records 1080p at 30 fps and 720p at 60 fps for smooth video
  • Adjustable focus with 3.6 mm lens and 72° field of view suits varied scenes
  • 5 MP OV5647 sensor captures 2592 × 1944 stills and 640 × 480 video at up to 90 fps

Raspberry Pi Camera Module with IR-Cut

This 5-megapixel camera module adds day and night vision to Raspberry Pi boards through an automatic IR-cut filter. It captures 2592 by 1944 pixel stills and records 1080p at 30 frames per second or 720p at 60 frames per second. The 72-degree field of view suits general monitoring and robotics projects. Builders wanting a ready-to-use vision sensor for a Pi will find it straightforward.

Check CSI Port and Ribbon Length Before Buying

The module connects through the dedicated CSI ribbon cable on the Raspberry Pi board. Verify that your Pi model — including Pi 4, 3, 2, 1, Zero or Zero W — exposes an accessible CSI connector and that the supplied ribbon reaches it inside your enclosure. Boards without a CSI port or cases that block the connector cannot use this camera. Buyers needing USB video input should look elsewhere.

Adjustable Focus and Fixed Optics Included

A 3.6-millimetre lens with adjustable focus and an aperture of 1.8 is fitted, giving the stated 72-degree view. The IR-cut mechanism switches automatically between day and night modes without extra software steps. No additional lenses, mounts or infrared illuminators are bundled, so plan any housing or lighting separately. Users requiring interchangeable optics or wider angles will need a different module.

Highlights

  • Automatic day-night switching avoids colour cast and keeps images clear
  • CSI interface delivers higher bandwidth for 5 MP data transfer to the processor
  • Records 1080p at 30 fps and 720p at 60 fps for smooth video
  • Adjustable focus with 3.6 mm lens and 72° field of view suits varied scenes
  • 5 MP OV5647 sensor captures 2592 × 1944 stills and 640 × 480 video at up to 90 fps

Specifications

TypeOthers

Questions about this item

What comes in the box with the BONAEVER 5MP IR-Cut Camera Module and do I need to buy a CSI cable separately?

The module includes the camera board with an integrated IR-cut filter, an adjustable 3.6 mm lens and a CSI ribbon cable for direct connection to the Raspberry Pi CSI port. No extra cable is required.

Should I choose the 1080p30 or 720p60 mode for my project with this 5MP Ov5647 sensor?

Use 1080p at 30 fps when you need the full 2592 x 1944 still resolution or maximum horizontal detail. Switch to 720p at 60 fps for smoother motion capture or when processing bandwidth is limited.

What does the 72° field of view mean once the camera is mounted on a Raspberry Pi 4?

The 72° diagonal angle covers a wide scene without fisheye distortion. At 1 metre distance the frame spans roughly 1.3 metres horizontally, suitable for room monitoring or robotics navigation.
