Five grey rectangular waterproof junction boxes with M20 cable glands

BONAEVER

BONAEVER 5 Pack IP68 Waterproof Junction Box M20 4 Pin AC 400V 24A

SKU CH-5X2C-N6CX5

Pack of five IP68-rated M20 junction boxes accept 5–12 mm cables for 400 V 24 A outdoor wiring

  • TypeWeatherproof Boxes
  • IP68 rating protects against water immersion up to 3.5 m
  • PA66 housing with V-0 flame retardancy operates from -40 °C to 105 °C
  • M20 4-pole connector accepts cables from Ø5-9 mm and 9-12 mm
  • UL, TUV, SAA, CE and RoHS certifications confirm safety compliance
  • Pack of five enables multiple outdoor lighting or signage connections

Outdoor waterproof junction box

The BONAEVER 5 Pack IP68 Waterproof Junction Box is a 2 way 4 pole M20 connector rated for AC 400V and 24A. It suits electricians and DIY installers who need reliable outdoor cable joins for lighting or signage circuits. Each connector includes two live wires one neutral and one earth wire.

Upgrade from basic glands

This connector replaces simple cable glands that lack integrated terminals and a high IP rating. The jump is worth it when a single fitting must join conductors seal against water and resist UV without extra enclosures. It covers cable diameters from 5 to 12 mm with two supplied rubber rings.

Sustained load behaviour

PA66 housing with V 0 flame retardancy operates continuously from minus 40 °C to 105 °C. IP68 sealing remains effective during prolonged immersion up to 3.5 m depth. The screw terminal block and clamping nut maintain contact pressure and seal integrity over long term thermal cycling.

Highlights

  • IP68 rating protects against water immersion up to 3.5 m
  • PA66 housing with V-0 flame retardancy operates from -40 °C to 105 °C
  • M20 4-pole connector accepts cables from Ø5-9 mm and 9-12 mm
  • UL, TUV, SAA, CE and RoHS certifications confirm safety compliance
  • Pack of five enables multiple outdoor lighting or signage connections

Specifications

TypeWeatherproof Boxes

Questions about this item

What cable diameter does the M20 junction box accept?

The box includes two rubber rings covering Ø5-9mm and Ø9-12mm cable ranges.

Which step is most often missed when installing the connector?

After wiring the live, neutral and earth terminals, every clamping nut must be fully tightened to seal the IP68 rating.

How long can the PA66 housing stay submerged at the rated depth?

The IP68 rating allows continuous immersion up to 3.5m; the V-0 flame-retardant PA66 housing is rated for -40°C to 105°C operation.
