Small rectangular development board with a 1.9-inch colour screen and solar connector

Bolton Technical

Bolton Technical 2 in 1 accessory

SKU CH-M2VY-B0M3W

A Meshtastic-ready LoRa tracker with a 1.9-inch colour display, GNSS positioning and solar or LiPo power options

  • Ready for mesh networking with pre-flashed Meshtastic firmware
  • Low power draw extends battery life to 11 uA in deep sleep
  • Clear outdoor visibility on 1.9-inch 262k-colour TFT display
  • Long-range 902-928 MHz LoRa links via SX1262 transceiver
  • Flexible expansion with LiPo, solar and GNSS connectors

LoRa Tracker with Meshtastic Firmware

This development kit combines a Nordic NRF52840 SoC with an SX1262 LoRa transceiver operating at 902 to 928 MHz. It arrives pre-flashed with Meshtastic firmware for long-range mesh messaging and includes a 1.9-inch TFT-LCD panel showing 170 by 320 pixels at up to 262k colours.

Suited for developers and outdoor communicators

Engineers building Meshtastic nodes or testing LoRaWAN, Thread and Zigbee protocols will benefit from the integrated GNSS module and Bluetooth 5 connectivity. Buyers needing cellular backhaul, Wi-Fi networking or a larger display should consider other platforms.

Solar and battery interfaces extend field life

A 1.25 mm 2-pin LiPo connector and matching solar-panel connector let the board run from rechargeable packs or direct sunlight. The 1.25 mm 8-pin GNSS header adds positioning flexibility, while Arduino-compatible libraries simplify custom firmware development.

Highlights

  • Ready for mesh networking with pre-flashed Meshtastic firmware
  • Low power draw extends battery life to 11 uA in deep sleep
  • Clear outdoor visibility on 1.9-inch 262k-colour TFT display
  • Long-range 902-928 MHz LoRa links via SX1262 transceiver
  • Flexible expansion with LiPo, solar and GNSS connectors

Specifications

No published specifications for this item yet.

Questions about this item

Do I need a separate LiPo battery to power the 1.25*2P connector on this tracker?

Yes, the board provides a 1.25*2P LiPo connector but no battery is included; you must supply your own compatible cell.

Can I keep my existing Arduino sketches when moving to this Nordic nRF52840 board?

The device is Arduino-compatible and ships with Meshtastic firmware; most sketches recompile for the nRF52840 core with minor pin-map changes.

How do I verify the 1.9-inch TFT-LCD is alive after first boot?

The screen shows 170 by 320 pixels in up to 262k colours; a successful start displays the Meshtastic logo and radio status on the panel.
