Small black metal box with HDMI input and dual SDI outputs

Blackmagic Design Pty. Ltd.

Blackmagic Design Pty. Ltd. Mini Converter HDMI to SDI 6G Media Converter BMD-CONVMBHS24K6G

SKU CH-2GBP-ZB2DM MPN BMD-CONVMBHS24K6G

Converts HDMI to dual 6G-SDI with 4:2:2 sampling, 48 kHz audio, and reclocking for SD, HD, and Ultra HD formats

  • SDI ComplianceSMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M,
  • Video SamplingSDI Video Sampling 4:2:2
  • Audio SamplingSDI Audio Sampling Television standard sample rate of 48 kHz
  • ColorSDI Color Precision: 4:2:2 SDI Color Space: YUV HDMI Color S
  • Copy ProtectionHDMI input is unable to capture from copy protected HDMI sou
  • VideoSD Video Standards 625i25 PAL, 525i29.97 NTSC HD Video Stand
  • Converts HDMI to SDI for SD, HD and Ultra HD workflows
  • Reclocked SDI outputs maintain signal integrity over long cable runs
  • Embeds 4-channel AES/EBU or 2-channel balanced analog audio into SDI
  • USB software control on macOS 10.12+ and Windows 8.1+
  • Compact 0.90" × 4.49" × 3.63" metal enclosure draws 4.44 W

Mini Converter HDMI to SDI 6G — Purpose

The Blackmagic Design Mini Converter HDMI to SDI 6G accepts an HDMI type A input and delivers two reclocked SDI outputs that automatically match SD, HD or 6G-SDI rates. It supports SMPTE 259M, 292M, 296M, 372M, 424M, 425M Level A or B and ST-2081 plus ITU-R BT.656 and BT.601. Video sampling is 4:2:2 with YUV colour space on SDI and YUV or RGB on HDMI at 4:2:2 or 4:4:4 precision. Audio includes four channels of AES/EBU digital audio and two channels of balanced analogue audio on quarter‑inch jacks.

Who This Suits — Who Should Look Elsewhere

Broadcasters and post‑production engineers who need reliable HDMI‑to‑SDI conversion for SD, HD, Ultra HD and DCI 4K formats up to 2160p30 will find the multi‑rate auto‑detection and reclocking useful. The unit also serves live‑event crews embedding external AES/EBU or analogue audio into the SDI stream. Buyers who require capture from copy‑protected HDMI sources cannot use this converter because the HDMI input rejects HDCP content. Users needing 12G‑SDI bandwidth or frame rates above 2160p30 should look at higher‑bandwidth models.

Bundled Accessories and Software Impact

A universal 12 V power supply with international socket adapters and a cable tie point is included, allowing operation from 12‑31 V DC at 4.44 W without sourcing a separate brick. Configuration and firmware upgrades are handled through the supplied USB updater application on macOS 10.12 Sierra or later and Windows 8.1 or 10, so no extra licences or tools are required to keep the converter current.

Highlights

  • Converts HDMI to SDI for SD, HD and Ultra HD workflows
  • Reclocked SDI outputs maintain signal integrity over long cable runs
  • Embeds 4-channel AES/EBU or 2-channel balanced analog audio into SDI
  • USB software control on macOS 10.12+ and Windows 8.1+
  • Compact 0.90" × 4.49" × 3.63" metal enclosure draws 4.44 W

Specifications

BrandBlackmagic Design
ModelBMD-CONVMBHS24K6G
SDI ComplianceSMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M Level A or Level B, SMPTE ST-2081, ITU-R BT.656 and ITU-R BT.601.
Video SamplingSDI Video Sampling
4:2:2
Audio SamplingSDI Audio Sampling
Television standard sample rate of 48 kHz and 24-bit.
ColorSDI Color Precision: 4:2:2
SDI Color Space: YUV
HDMI Color Space: YUV and RGB
HDMI Color Precision: 4:2:2 and 4:4:4
Copy ProtectionHDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
VideoSD Video Standards
625i25 PAL, 525i29.97 NTSC
HD Video Standards
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
4K Video Standards
4K DCI 23.98p, 4K DCI 24p, 4K DCI 25p
HDMI Video Standards
625i25 PAL, 525i29.97 NTSC
720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
1080i50, 1080i59.94, 1080i60
2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30
HDMIHDMI type A in
SDI2 x SDI Video Outputs. Automatically matches the SD, HD and 6G-SDI HDMI video input.
Digital Aduio4 channels of AES/EBU digital audio.
Analog Aduio2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
SoftwareSoftware Control
Mac OS and Windows software upgrade via USB.
Internal Software Upgrade
Via included updater application.
CompatibilitymacOS 10.12 Sierra, macOS High Sierra 10.13 or later.
Windows 8.1 or Windows 10.
Power Consumption4.44 Watts
Power Supply+12V universal power supply included with international socket adapters for all countries. Cable tie point.
Operational Voltage Range
12 - 31V DC
SpecificationConnections:
Multi Rate Support: Auto detection of SD, HD or 6G-SDI.
Updates and Configuration: USB
Reclocking: Yes
Standards:
SDI Video Rates: SDI video connections are switchable between SD, HD, Ultra HD and DCI 4K
SDI Auto Switching: Automatically detects SD, HD or 6G-SDI
Format Conversion:
HD down conversion
Settings Control:
Mini Switches or USB software
Environmental Specifications:
Operating Temperature: 0 to 40 celsius degree
Storage Temperature: -20 to 45 celsius degree
Relative Humidity: 0% to 90% non-condensing
FeatureMini Converter HDMI to SDI 6G includes everything you need to convert from HDMI devices to SDI video in SD, HD and Ultra HD video formats. With independent audio connections you can also embed SDI audio from HDMI, AES/EBU or balanced analog audio inputs. Mini Converter HDMI to SDI is the perfect solution to convert HDMI consumer cameras or computers to broadcast quality SDI!
Dimensions0.90" x 4.49" x 3.63"
Weight8.60 oz.
Shipping weight0.45 kg
Package size152 × 152 × 51 mm

Questions about this item

What HDMI source do I need to connect to the type A input for the converter to work?

Any device with an HDMI type A output that is not copy-protected, such as a camera, recorder or computer graphics card, will drive the converter.

Will my existing SD-SDI monitor accept the signal from the two 6G-SDI outputs?

Yes — the outputs auto-detect and reclock SD, HD, 3G and 6G rates, so a legacy SMPTE 259M monitor will display the down-converted picture.

How can I verify the converter is passing 4:2:2 YUV video at 48 kHz 24-bit audio after setup?

Use the USB control panel on macOS 10.12 or later or Windows 8.1/10 to read the detected video standard, sampling and audio status reported by the firmware.
