Compact black metal box with eight BNC outputs on one side

Blackmagic Design Pty. Ltd.

Blackmagic Design Mini Converter SDI Distribution 4K CONVMSDIDA4K media converter

SKU CH-PYY4-ZSK0F MPN CONVMSDIDA4K

Distributes a single SDI signal to eight re-clocked outputs with automatic format detection up to 4K

  • FormatSD Format Support 525/29.97 NTSC, 625/25 PAL HD Format Suppo
  • SDI ComplianceSMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425
  • SDISDI Video Rates SDI video connections are switchable between
  • System RequirementsOperating Systems Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yo
  • Power Consumption4.80 Watts
  • Power Supply+12V universal power supply included with international sock
  • Distributes one SDI source to eight re-clocked outputs simultaneously
  • Auto-detects SD, HD, 3G and 6G-SDI input formats
  • Supports Ultra HD 4K up to 30 fps and DCI 4K at 24 fps
  • Operates from 0° to 40° C with 4.80 W power draw
  • Includes 12 V universal supply with international socket adapters

Signal distribution scope

The Blackmagic Design Mini Converter SDI Distribution 4K takes one Single Link SD, HD, 3G or 6G-SDI input and delivers eight re-clocked SDI outputs. It is built for broadcast, post-production and professional AV workflows that need a single source sent to multiple monitors, recorders or switchers without signal degradation.

Build and connectivity

The ultra-compact metal enclosure houses eight BNC outputs and one BNC input, all supporting 4:2:2 and 4:4:4 sampling at 48 kHz 24-bit audio. A 12 V universal power supply with international socket adapters and a cable tie point is included. Operating temperature ranges from 0 °C to 40 °C with humidity up to 90 % non-condensing.

Format limits

Automatic input detection handles SD-SDI, HD-SDI, 3G-SDI and 6G-SDI rates compliant with SMPTE 259M, 292M, 296M, 372M and 425M. Maximum supported resolutions are Ultra HD 4K at 3840 × 2160 up to 30 fps and DCI 4K at 4096 × 2160 at 24 fps. It does not support 12G-SDI rates or resolutions beyond 4K.

Highlights

  • Distributes one SDI source to eight re-clocked outputs simultaneously
  • Auto-detects SD, HD, 3G and 6G-SDI input formats
  • Supports Ultra HD 4K up to 30 fps and DCI 4K at 24 fps
  • Operates from 0° to 40° C with 4.80 W power draw
  • Includes 12 V universal supply with international socket adapters

Specifications

BrandBlackmagic Design
SeriesMini Converter
ModelCONVMSDIDA4K
FormatSD Format Support
525/29.97 NTSC, 625/25 PAL
HD Format Support
720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080p23.98, 1080PsF23.98, 1080p24, 1080PsF24, 1080p25, 1080PsF25, 1080p29.97, 1080PsF29.97, 1080p30, 1080PsF30, 1080p50, 1080p59.94, 1080p60
2K Format Support
2048x1080PsF23.98, 2048x1080p23.98, 2048x1080PsF24, 2048x1080p24, 2048x1080PsF25, 2048x1080p25
4K Format Support
3840x2160p23.98, 3840x2160p24, 3840x2160p25, 3840x2160p29.97, 3840x2160p30, 4096x2160p24
SDI ComplianceSMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M and SMPTE 425M
SDISDI Video Rates
SDI video connections are switchable between 6G-SDI, HD and SD-SDI
SDI Video Sampling
4:2:2 and 4:4:4
SDI Audio Sampling
Television standard sample rate of 48 kHz and 24 bit.
SDI Color Precision
4:2:2 and 4:4:4
SDI Color Space
YUV and RGB
SDI Auto Switching
Automatically selects between SD SDI, HD-SDI and 3G- SDI.
System RequirementsOperating Systems
Mac OS X 10.9 Mavericks, Mac OS X 10.10 Yosemite or later.
Windows 7 or Windows 8.
Power Consumption4.80 Watts
Power Supply+12V universal power supply included with international socket adapters for all countries. Cable tie point.
SpecificationOperating temperature
0° to 40° C (32° to 104° F)
Storage temperature
-20° to 45° C (-4° to 113° F)
Relative Humidity
0% to 90% non-condensing
FeatureThe Mini Converter SDI Distribution 4K from Blackmagic Design allows you to distribute a Single Link SD/HD/3G/6G-SDI signal to eight SDI devices simultaneously. It automatically detects the input signal type, re-clocks it, and its eight outputs automatically match the SDI input video format. With a compact form factor and easy-to-use controls, the Mini Converter is ideal for a variety of broadcast, post production, and professional AV applications.
Using 6G-SDI technology, the Mini Converter supports resolutions up to Ultra HD 4K (3840 x 2160) at up to 30 fps and DCI 4K (4096 x 2160)
Package ContentMini Converter SDI Distribution 4K
Software CD
12V universal power supply with international socket adapters
Shipping weight0.45 kg
Package size152 × 102 × 51 mm

Questions about this item

What SDI standards does the CONVMSDIDA4K comply with and what video rates do they cap?

It complies with SMPTE 259M, 292M, 296M, 372M and 425M, and its SDI connections switch between 6G-SDI, HD-SDI and SD-SDI.

What physical mounting or clearance does the Mini Converter SDI Distribution 4K require?

The ultra-compact unit needs only a flat surface; a cable tie point on the 12 V supply secures the power lead.

How is the converter installed and which step do users often miss?

Connect the SDI source to the single input, link up to eight devices to the outputs, attach the 12 V universal supply with the correct adapter, then power on — the unit auto-detects the signal format.
