Handheld ultrasonic thickness gauge in dark rubber housing with colour LCD screen and probe attached

BFKK

BFKK Ultrasonic Thickness Gauge PM1301D

SKU CH-1PD1-4WB4K

Measures material thickness from 0.039 to 11.811 inches non-destructively in 0.5 seconds with 0.0003 inch resolution and ±(0.5% H+0.001 inches) accuracy

  • Non-destructive steel measurement from .039 to 11.811 inches in .5 seconds
  • Adjustable sound velocity 1000–9999 m/s with 12 material presets for accuracy
  • Color LCD backlight with min/max/average modes and data storage
  • Lightweight 5.57 oz design with 8-hour rechargeable battery life
  • Includes 5 MHz probe, gel, calibration block, USB-C cable and carrying case

Ultrasonic Gauge PM1301D

The PM1301D is a handheld ultrasonic thickness gauge designed for non-destructive testing of metal and non-metal materials. It serves engineers, inspectors and maintenance crews who need to verify wall thickness on pipes, vessels or structural components without cutting or damaging the part.

Rugged Handheld Build with USB-C Link

The unit weighs 5.57 oz and uses an ergonomic rubber housing that resists impacts during field work. A built-in 1000 mAh rechargeable battery provides up to 8 hours of continuous operation. The colour LCD backlight remains readable in bright or dim conditions. A USB-C cable enables direct connection to computer software for data recording and statistical analysis.

Replaces Manual Calipers and Single-Preset Gauges

The adjustable sound velocity range of 1000 to 9999 m/s with 12 material presets covers steel, plastics, glass, PVC and ceramics in one instrument. It supersedes tools limited to a single material setting or those lacking data-logging capability. The jump is worthwhile when you measure dissimilar materials daily and need stored records for quality audits.

Highlights

  • Non-destructive steel measurement from .039 to 11.811 inches in .5 seconds
  • Adjustable sound velocity 1000–9999 m/s with 12 material presets for accuracy
  • Color LCD backlight with min/max/average modes and data storage
  • Lightweight 5.57 oz design with 8-hour rechargeable battery life
  • Includes 5 MHz probe, gel, calibration block, USB-C cable and carrying case

Specifications

No published specifications for this item yet.

Questions about this item

What measurement range does the PM1301D cover in steel?

The gauge measures steel from 0.039 to 11.811 inches with a resolution of 0.0003 inches and accuracy of ±(0.5% H+0.001 inches).

Which probe and accessories come in the box for mounting and coupling?

The kit includes a 5MHz probe, ultrasonic coupling gel, a built-in metal calibration block, USB-C cable and a carrying case.

How do you set the correct sound velocity before taking readings?

Select one of the 12 material presets or manually adjust the velocity between 1000 and 9999 m/s, then verify on the supplied calibration block before measuring.
