Two white rectangular outdoor wireless bridges with integrated directional antennas and pole mounting brackets

BFKK

BFKK CPE453 5.8G 14dBi Outdoor Bridge 2-Pack

SKU CH-JYWW-QDBA5

Two 5.8 GHz outdoor bridges with 14 dBi directional antennas extend a network up to 3 km using 24 V PoE or 12 V DC power

  • Enterprise-class 802.11ac bridge extends network up to 3 km
  • 14 dBi dual-polarized directional antenna boosts 5.8 GHz signal strength
  • IP65 weatherproof housing withstands extreme outdoor conditions
  • 24 V PoE or 12 V DC power over 50–70 m cable
  • Digital-tube pairing links units without computer configuration

Outdoor wireless bridge pair

The BFKK CPE453 is a 5.8G outdoor wireless bridge sold as a matched pair. Each unit integrates a 14dBi directional antenna and a 100M Ethernet port for point-to-point or point-to-multipoint links up to 3 km. The kit targets installers who need to extend a network to a second building without trenching cable.

Thermals noise and power

The IP65-rated enclosure protects the radio against rain, dust and temperature extremes for continuous outdoor operation. Power is supplied by an included 24V passive PoE injector, allowing the Ethernet cable to carry both data and power over runs of 50 to 70 metres. A 12V 1A DC input provides a local-power alternative when PoE is not convenient.

Accessories and software

Two 24V PoE adapters and mounting hardware are bundled so both ends can be powered and secured immediately. The manufacturer highlights a digital-tube pairing function that links the two units without a computer, simplifying setup for installers without specialised networking training.

Highlights

  • Enterprise-class 802.11ac bridge extends network up to 3 km
  • 14 dBi dual-polarized directional antenna boosts 5.8 GHz signal strength
  • IP65 weatherproof housing withstands extreme outdoor conditions
  • 24 V PoE or 12 V DC power over 50–70 m cable
  • Digital-tube pairing links units without computer configuration

Specifications

No published specifications for this item yet.

Questions about this item

How do I pair the two CPE453 units without a computer?

Power both units with the 24V PoE adapters, aim the 14dBi directional antennas at each other, then press the digital-tube pairing button on each device; the units link automatically in point-to-point mode.

What power options does the CPE453 support for long cable runs?

The bridge accepts 24V passive PoE over Ethernet up to 50-70 metres depending on cable quality, or a local 12V 1A DC supply if an outlet is nearby.

What throughput ceiling will I hit first on a sustained link?

The 10/100 Mbps Ethernet port caps wired throughput at 100 Mbps, so extended transfers will be limited by that interface rather than the 5.8G wireless link.
