Chrome tailgate handle with integrated backup camera lens and RCA cable visible

BESIGN

BESIGN Tailgate Handle Backup Camera 2 in 1 accessory

SKU CH-ZSX2-6DHTV

Replaces the tailgate handle on 2002-2008 Dodge Ram 1500 2500 3500 with an IP67 camera offering 640×480 CVBS or 1280×720 AHD video and 140° night-vision view

  • Fits 2002–2008 Dodge Ram 1500 2500 3500 aftermarket radios
  • Switchable 640×480 CVBS with guidelines or 1280×720 PAL for sharper view
  • Infrared night vision sees farther in darkness than standard LED cameras
  • IP67 sealed silicone housing resists rain and car-wash water
  • Pull-handle mount with 10 m video cable simplifies installation

Tailgate Camera for Dodge Ram 2002-2008

This backup camera replaces the tailgate handle on 2002-2008 Dodge Ram 1500, 2500 and 3500 trucks. It connects to an aftermarket radio with an RCA input and is not compatible with factory OEM monitors or navigation units. The kit includes a 10 metre video cable, a 1 metre power cable, a waterproof ring and a manual for installation.

RCA Interface and Video System Limits

The camera outputs an analogue CVBS signal at 640 by 480 with parking guidelines under the NTSC system. Cutting the green control line switches the output to 1280 by 720 without guidelines under the PAL system, but the head unit must support PAL to display that resolution. The fixed RCA connector means the unit cannot be used with digital-only displays or wireless receivers.

IP67 Waterproof Rating

The housing meets the IP67 standard with a fully sealed, silicone-filled construction that resists water ingress during rain or vehicle washing. This rating is the primary durability specification for external mounting on the tailgate. Buyers who need a camera for factory infotainment systems or for vehicles outside the listed model years should look elsewhere.

Highlights

  • Fits 2002–2008 Dodge Ram 1500 2500 3500 aftermarket radios
  • Switchable 640×480 CVBS with guidelines or 1280×720 PAL for sharper view
  • Infrared night vision sees farther in darkness than standard LED cameras
  • IP67 sealed silicone housing resists rain and car-wash water
  • Pull-handle mount with 10 m video cable simplifies installation

Specifications

No published specifications for this item yet.

Questions about this item

Should I choose the 640×480 CVBS mode or the 1280×720 AHD mode for my aftermarket radio?

Use 640×480 CVBS with guidelines if your head unit only accepts NTSC composite video. Cut the green control wire to switch to 1280×720 AHD (PAL, no guidelines) when your aftermarket screen supports that higher resolution.

What does the 140-degree viewing angle actually show when I am reversing?

The 140-degree lens captures a wide field behind the Dodge Ram so you see both rear corners and the area directly behind the tailgate, helping you spot obstacles that a narrower camera would miss.

The camera uses an RCA connector — what does that limit in practice?

The RCA plug carries standard-definition composite video, so the maximum usable resolution is the 640×480 CVBS signal unless your aftermarket monitor can decode the 1280×720 AHD stream sent over the same cable.
