Black rectangular docking station with multiple ports on front and back, horizontal orientation

Belkin YYD0504A USB-C Docking Station 2HDMI DP 100W PD 14.33in

SKU CH-87KN-CG6BP MPN 3591/3581/3480/3580/3590/3490/5570/5680/5

Connects a laptop via USB-C to three 4K displays with 100 W power delivery and 10 Gbps data ports

  • ColorBlack
  • Compatibility(Smartphones,Projectors, Monitors, Laptops, Mouse/Keyboards,
  • Ports Spec1 x USB 2.0
  • Dimension14.33in W x 12.83in H x 9.06in D
  • FeaturesPlug and Play
  • Connect three monitors with 2 HDMI 4K@60Hz and 1 DP up to 8K@30Hz
  • Charge laptop at 87W via 100W PD pass-through while dock runs on 13W
  • Transfer files at 10Gbps through two USB-A 3.0 and one USB-C 3.0 ports
  • Works with Thunderbolt 3/4 and full-function USB-C laptops including Dell HP Lenovo MacBook
  • Plug-and-play design requires no driver installation for instant multi-display setup

Triple-monitor dock for Thunderbolt laptops

This Belkin USB-C docking station expands a single Thunderbolt 3 or 4 port into seven connections. It adds two HDMI outputs, one DisplayPort, two USB-A 3.0 ports, one USB-C 3.0 port and a 100 W USB-C Power Delivery pass-through. The unit is aimed at professionals who need three external screens and high-speed peripherals from one cable.

Three 4K streams or one 8K panel

Two HDMI ports each drive 4K at 60 Hz while the DisplayPort handles 8K at 30 Hz, 4K at 144 Hz or 4K at 120 Hz. All three displays can run 4K 60 Hz simultaneously on a DisplayPort 1.4 host. macOS limits the arrangement to mirror mode, so extended desktops require Windows. The dock consumes 13 W internally, leaving 87 W for laptop charging.

Silent operation with external power

No fan is fitted, so the dock runs silently on the desk. It draws up to 13 W for its own circuitry and passes the remaining 87 W of the 100 W PD budget to the host. An external 100 W USB-C charger must be supplied separately; without it the downstream ports may not function reliably.

Highlights

  • Connect three monitors with 2 HDMI 4K@60Hz and 1 DP up to 8K@30Hz
  • Charge laptop at 87W via 100W PD pass-through while dock runs on 13W
  • Transfer files at 10Gbps through two USB-A 3.0 and one USB-C 3.0 ports
  • Works with Thunderbolt 3/4 and full-function USB-C laptops including Dell HP Lenovo MacBook
  • Plug-and-play design requires no driver installation for instant multi-display setup

Specifications

BrandBelkin
Series2 HDMI + 1 DisplayPort, LSIKMC
ModelYYD0504A
Part NumberYY-0504
ColorBlack
Compatibility(Smartphones,Projectors, Monitors, Laptops, Mouse/Keyboards, Dell/HP/Lenovo/Samsung, MacBook Pro/Air) Laptop with Thunderbolt or Full function USB C port
Ports Spec1 x USB 2.0
Dimension14.33in W x 12.83in H x 9.06in D
FeaturesPlug and Play

Questions about this item

Will this dock work with my older laptop that only has a standard USB-C port without Thunderbolt?

The dock requires a full-featured USB-C port that supports DisplayPort Alternate Mode and Power Delivery; a basic USB 2.0 or 3.0 port without video output will not drive the external monitors.

How can I verify the DisplayPort output is running at 8K 30 Hz or 4K 144 Hz after I connect my monitor?

Open your OS display settings and check that the external screen shows the selected resolution at the target refresh rate; the dock's DP 1.4 link supports up to 8K at 30 Hz and 4K at 144 Hz.

Does the package include a 100 W power adapter so I can charge my laptop through the dock?

No charger or cable is included; you must connect your own USB-C PD power supply to the dock's charging port to deliver up to 87 W to the laptop after the dock draws its 13 W.
