Compact silver rectangular dock with front Thunderbolt 3 port and audio jack

Belkin

Belkin F4U109TT Thunderbolt 3 Dock Plus docking station

SKU CH-0NPY-WCHD6 MPN F4U109TT

Connects a laptop to dual 4K monitors, six USB ports, gigabit Ethernet and audio while delivering 60 W charging over a single Thunderbolt 3 link

  • CompatibilitySystem requirements: macOS Sierra 10.12 or later Windows 10
  • Thunderbolt 3Yes
  • Ports SpecFront: 1 x Thunderbolt 3 Type-C port with PD 3.0 delivers ch
  • Dimension1.22" x 6.52" x 3.06" (H x W x D)
  • Weight267g / 9.42 oz.
  • ContentThunderbolt 3 Dock Plus 0.5m / 1.6ft. Thunderbolt 3 cable

Option Thunderbolt Plus

  • Dual 4K monitors at 60 Hz for expanded workspace
  • 60 W laptop charging through front Thunderbolt 3 port
  • 40 Gbps data transfer via Thunderbolt 3 connection
  • Six USB ports plus Gigabit Ethernet for all peripherals
  • Compact 1.22 x 6.52 x 3.06 inch design weighs 267 g

Universal dock for Thunderbolt 3 laptops

The Belkin F4U109TT Thunderbolt 3 Dock Plus connects macOS Sierra 10.12 or later and Windows 10 or later notebooks through a single 1.6 ft cable. It consolidates six USB ports, dual DisplayPort outputs, Gigabit Ethernet and a 3.5 mm audio combo jack into one compact hub.

Dual 4K 60 Hz or single 8K 30 Hz video headroom

Two DisplayPort connectors drive two 4K monitors at 60 Hz or one 8K display at 30 Hz. The front Thunderbolt 3 Type-C port supplies up to 60 W of Power Delivery 3.0 charging to the host while the dock draws from its 125 W supply.

40 Gbps Thunderbolt 3 bandwidth ceiling

Aggregate throughput tops out at 40 Gbps, so simultaneous high-resolution video, 10 Gbps USB 3.1 Gen 2 traffic and gigabit networking share the same pipe. Systems lacking a native Thunderbolt 3 port fall back to standard USB-C speeds and lose the dual 4K 60 Hz capability.

Highlights

  • Dual 4K monitors at 60 Hz for expanded workspace
  • 60 W laptop charging through front Thunderbolt 3 port
  • 40 Gbps data transfer via Thunderbolt 3 connection
  • Six USB ports plus Gigabit Ethernet for all peripherals
  • Compact 1.22 x 6.52 x 3.06 inch design weighs 267 g

Specifications

BrandBelkin
ModelF4U109tt
Part NumberF4U109TT
CompatibilitySystem requirements:
macOS Sierra 10.12 or later
Windows 10 or later
Thunderbolt 3Yes
Ports SpecFront:
1 x Thunderbolt 3 Type-C port with PD 3.0 delivers charging (up to 60W) to laptop with the included Thunderbolt 3 Gen 2 cable
1 x Audio in/out for mic and speaker support
1 x USB-A 3.1 Gen 2 port for USB-A peripherals
Back:
1 x Gigabit Ethernet connection
2 x USB-A 3.1 Gen 1 ports for devices that connect via USB-A such as a mouse, keyboard or printer
2 x USB-C 3.1 Gen 2 ports for USB-C peripherals
2 x DisplayPort 1.4 connect to high-resolution monitors/displays
Dimension1.22" x 6.52" x 3.06" (H x W x D)
Weight267g / 9.42 oz.
ContentThunderbolt 3 Dock Plus
0.5m / 1.6ft. Thunderbolt 3 cable
Shipping weight1.09 kg
Package size224 × 114 × 109 mm

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the Belkin F4U109TT Thunderbolt 3 Dock Plus work with my older USB-C laptop that does not have Thunderbolt?

The dock is compatible with macOS and Windows USB-C laptops; Thunderbolt speeds require a Thunderbolt 3 port, so non-Thunderbolt USB-C hosts will operate at their native USB-C speeds.

How can I verify the dock is delivering the full 40 Gbps Thunderbolt 3 link after I connect it?

On macOS open System Information and check the Thunderbolt tree for a 40 Gbps link; on Windows open Thunderbolt Control Center and confirm the connection shows 40 Gbps.

What cables and accessories come in the box with the Belkin F4U109TT and what must I provide myself?

The package includes the Thunderbolt 3 Dock Plus and a 1.6 ft Thunderbolt 3 cable; you will need to supply your own DisplayPort cables for monitors, USB peripherals and an Ethernet cable if you use the Gigabit port.
