Belkin
Belkin F1DH102L 2-Port VGA USB KVM Switch
A 2-port VGA and USB KVM switch supporting 2048 x 1536 resolution with hot-key switching, front-panel LEDs, a built-in USB 2.0 hub, and included colour-coded cables
- TypeD-Sub, USB
- PC ConnectorsDisplay / video : 4 x VGA - 15 pin HD D-Sub (HD-15) Micropho
- Console Connectors2 x KVM / audio / USB
- Computer Connections2 Ports
- Monitor Connections1 Port
- Video Resolution2048 x 1536
- Switch between two computers with front-panel buttons
- Supports up to 2048 x 1536 video resolution
- Built-in USB 2.0 hub connects peripherals
- Hot-key switching works without installing software
- Color-coded cables simplify the installation process
Two-Port KVM for Mac and PC
The Belkin F1DH102L lets one keyboard, mouse and VGA monitor control two computers. It switches between Mac and PC platforms without installing any software. Front-panel buttons with LED indicators show the active port at a glance. A built-in USB 2.0 hub adds two ports for extra peripherals.
Video up to 2048 x 1536
The switch supports a maximum resolution of 2048 x 1536 over its single VGA console port. Each computer connection uses a 15-pin HD-15 video cable plus 3.5 mm audio jacks for microphone and headphones. The USB link handles keyboard and mouse signals. Two computers is the hard limit; a third system cannot be added.
Color-coded cables and hot-key switching
The package includes color-matched cables that correspond to the front buttons and rear panel, simplifying the initial wiring. Hot-key sequences provide an alternative way to change ports without reaching for the switch. No driver disc or configuration utility is required, so the unit is ready to use once the cables are connected.
Highlights
- Switch between two computers with front-panel buttons
- Supports up to 2048 x 1536 video resolution
- Built-in USB 2.0 hub connects peripherals
- Hot-key switching works without installing software
- Color-coded cables simplify the installation process
Specifications
| Brand | BELKIN |
|---|---|
| Model | F1DH102L |
| Type | D-Sub, USB |
| PC Connectors | Display / video : 4 x VGA - 15 pin HD D-Sub (HD-15) Microphone : 2 x mini-phone 3.5 mm Headphones : 2 x mini-phone stereo 3.5 mm Display / video : 2 x VGA - 15 pin HD D-Sub (HD-15) Keyboard : 1 x 4 pin USB Type A Mouse : 1 x 4 pin USB Type A USB : 2 x 4 pin USB Type A Microphone : 1 x mini-phone 3.5 mm Headphones : 1 x mini-phone stereo 3.5 mm |
| Console Connectors | 2 x KVM / audio / USB |
| Computer Connections | 2 Ports |
| Monitor Connections | 1 Port |
| Video Resolution | 2048 x 1536 |
| PC Selection | Hot Keys |
| Features | Switches easily between Mac computers and PCs Front-panel buttons with NEW LED indicator lights allow you access audio and video content from multiple computers simultaneously Requires no software for installation Now includes a built-in USB 2.0 hub for connecting your peripherals Included cables are color-coded to match the front buttons and back panel for trouble-free installation Now supports hot-key functionality for optional switching |
| Dimensions | 5.50" x 12.60" x 5.50" |
| Weight | 1.50 lbs. |
| Shipping weight | 3.18 kg |
| Package size | 368 × 254 × 23 mm |
Questions about this item
Will this Belkin F1DH102L share my existing VGA monitors and USB keyboard without extra adapters?
Yes, the console side provides two VGA ports and one USB Type A port for keyboard and mouse, so your current VGA displays and USB peripherals plug in directly.
How do I confirm the Belkin F1DH102L is switching correctly after I connect everything?
Press the front-panel buttons and watch the new LED indicator lights; they show which computer port is active and the switch changes video, audio and USB together.
Which cables come with the Belkin F1DH102L and what must I supply myself?
The box includes the KVM switch and color-coded cables for two computers; you only need to provide your own VGA monitor cable, USB keyboard, mouse and 3.5 mm audio leads.
