Barco
Barco R9861005NA digital signage media player
Wireless presentation system drives dual displays at up to 30 fps and supports 64 connected Buttons for simultaneous content sharing from laptops, iOS and Android devices
- VideoVideo outputs DisplayPort, Single link DVI-I VGA (via includ
- AudioAnalog audio from ClickShare CSC Base Unit software v01.02.0
- Network Interface1x Ethernet LAN
- USB Port4x (back) + 1x (front) USB
- Other ConnectorAnalog line out on mini jack socket (3.5mm) Analog line in o
- System RequirementsPC minimum requirements: CPU: Intel Pentium Dual Core E2140
- Wireless presentation with a single button click
- Dual-screen output via DisplayPort and DVI-I
- Up to 64 Buttons paired for instant sharing
- Four users displayed simultaneously on one screen
- Low power draw: 2.5 W shutdown, 20 W typical
Meeting-room presentation hub
The Barco R9861005NA is a ClickShare CSC-1 Base Unit built for conference rooms and boardrooms that need wireless sharing from laptops, tablets or phones. It accepts up to 64 paired Buttons and the ClickShare apps for iOS and Android, letting four participants show content side by side. The unit ships new and includes a VGA converter for legacy displays.
Upgrade from single-screen ClickShare
Earlier Base Units limited you to one display output; this model adds dual-screen support through DisplayPort and DVI-I, or VGA with reduced blanking at the highest resolutions. The jump is worth it when you drive two projectors, two flat panels or a Double HD canvas and want simultaneous multi-user viewing without swapping cables. Analog line-in and line-out on 3.5 mm jacks handle room audio.
Interface and power limits
Video leaves the box over DisplayPort, single-link DVI-I or VGA, so 4K or high-refresh formats beyond the specified 30 fps ceiling are not supported. The Ethernet port provides a single wired LAN link; no wireless back-haul or additional network interfaces are present. Power draw peaks at 35 W, idles at 2.5 W and typically runs at 20 W, so the supply must deliver that headroom.
Highlights
- Wireless presentation with a single button click
- Dual-screen output via DisplayPort and DVI-I
- Up to 64 Buttons paired for instant sharing
- Four users displayed simultaneously on one screen
- Low power draw: 2.5 W shutdown, 20 W typical
Specifications
| Brand | Barco |
|---|---|
| Model | R9861005NA |
| Video | Video outputs DisplayPort, Single link DVI-I VGA (via included convertor, highest resolutions only with reduced blanking) In "Dual screen" mode, connection can occur either through DVI and DisplayPort, or through VGA and DisplayPort. |
| Audio | Analog audio from ClickShare CSC Base Unit software v01.02.00.09 onwards Digital audio (embedded in DP signal) from ClickShare CSC Base Unit software v01.05.00.32 onwards |
| Network Interface | 1x Ethernet LAN |
| USB Port | 4x (back) + 1x (front) USB |
| Other Connector | Analog line out on mini jack socket (3.5mm) Analog line in on mini jack socket (3.5mm) |
| System Requirements | PC minimum requirements: CPU: Intel Pentium Dual Core E2140 - 2 * 1600 Mhz (or equivalent: AMD Athlon 64 X2 3800+ - 2 * 2000 Mhz) Memory: 1024 MB RAM OS: Windows XP Pro/Home (SP3) (Windows Vista/7 supported, but requires more RAM) PC recommended requirements: CPU: Intel Core 2 Duo E4600 - 2 * 2400 Mhz (or equivalent: AMD Athlon 64 X2 4800+ - 2 * 2500 Mhz) Memory: 2048 MB RAM OS: Windows XP Pro/Home, Windows Vista, Windows 7, Windows 8 MAC CPU: Intel Core 2 Duo Memory: 2048 MB RAM OS: Mac OS X 10.6, 10.7, 10.8 |
| Power Consumption | Shutdown: 2.5W Operation (typical): 20W Maximum: 35W |
| Specification | Operating system Windows 7/8/8.1/10 32 & 64 bit Mac OSX 10.10/10.11 Android v5 & v6 (ClickShare app) iOS 8 & 9 (ClickShare app) Frame rate: Up to 30 fps (from software version V1.03.00.0001 onwards) Output resolution: UHD (3840 x 2160) available from ClickShare CSC Base Unit software v01.09.00.22 onwards Noise Level: Max. 28dBA Number of sources simultaneous on screen: 4 Number of simultaneous connections: 64 iPad, iPhone and Android compatibility Available via ClickShare app for static content. For iOS devices using iOS9, full mirroring is possible from ClickShare CSC Base Unit firm |
| Dimensions | 7.13" (incl. antennas) x 10.24" x 10.90" (Min.) |
| Weight | 5.75 lbs. |
| Shipping weight | 5.90 kg |
| Package size | 467 × 330 × 135 mm |
Questions about this item
What rack space and clearance does the 7.13" x 10.24" x 10.90" unit need?
The base unit measures 7.13 inches high including antennas, 10.24 inches wide and 10.90 inches deep at minimum, so allow at least that footprint plus cable bend radius behind the rear USB and video ports.
Which video outputs must be used together for dual-screen mode during setup?
Connect one display to the DisplayPort and the second to the single-link DVI-I, or use the included VGA converter on the DVI-I port; the firmware requires those specific pairs for dual-screen operation.
When will the internal power supply or fan need replacement given the 35 W maximum draw?
The supply is rated for continuous operation at up to 35 W and typical 20 W; no user-serviceable fan or power module is documented, so plan on full-unit replacement if either fails.
