Red barrel ultrasonic sensor with 2 m cable and teach button

Banner

Banner T30UINB 2 m range ultrasonic sensor

SKU CH-37W4-0EH0P MPN T30UINB

Ultrasonic proximity sensor detects objects from 300 mm to 2 m with NPN and 4-20 mA outputs on a 2 m cable

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 2 m sensing range for tank-level monitoring
  • 300 mm minimum distance avoids blind-zone errors
  • 12–24 V dc supply fits standard control panels
  • NPN discrete plus 4–20 mA analog outputs simplify wiring
  • MIL-STD-202F vibration and IEC 60947-5-2 shock ratings ensure durability

Ultrasonic sensor for pump control

The Banner T30UINB is a barrel-style ultrasonic sensor designed for proximity detection in pump control applications. It operates on a 12 to 24 V dc supply and provides both a discrete NPN output and a 4 to 20 mA analog signal. The sensing range spans 300 mm to 2000 mm using a time-of-flight ultrasonic beam. A teach button allows simple range adjustment without a PC connection.

Check power supply and wiring compatibility

Verify that your system can deliver 12 to 24 V dc to the sensor's five-pin cable connection. The discrete NPN switched output supports up to 100 mA with a saturation voltage below 1.0 V at 10 mA and below 1.5 V at 100 mA. The analog current output requires a load resistance between 1 ohm and (Vcc minus 7 V) divided by 0.02 A. No quick-disconnect fitting is present, so the 2 m cable must be terminated directly or via a junction box.

PBT housing rated for shock and vibration

The red PBT barrel housing meets MIL-STD-202F Method 201A for vibration (10 to 60 Hz, 0.06 inch double amplitude, 10 G max acceleration) and IEC 60947-5-2 for mechanical shock (30 G, 11 ms half sine). An LED indicator provides local status feedback. The fixed 2 m cable and lack of a quick-disconnect mean the sensor mounts permanently, so plan the cable route and strain relief during installation.

Highlights

  • 2 m sensing range for tank-level monitoring
  • 300 mm minimum distance avoids blind-zone errors
  • 12–24 V dc supply fits standard control panels
  • NPN discrete plus 4–20 mA analog outputs simplify wiring
  • MIL-STD-202F vibration and IEC 60947-5-2 shock ratings ensure durability

Specifications

BrandBANNER
ModelT30UINB
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What comes in the box with the T30UINB and what must I source separately?

The sensor is supplied in a single pack with a 2 m cable permanently attached; a 12-24 V dc power supply and any mounting hardware are not included.

Which sensing range version of the T30UINB should I select for my application?

This model covers 300 mm to 2000 mm using ultrasonic time-of-flight; choose it when your target falls inside that window.

What does the 2 m range mean when the sensor is installed in a real machine?

It detects objects from 300 mm out to 2000 mm, provides a 4-20 mA analog signal and a 100 mA NPN discrete output, with repeatability of ±0.25 % of measured distance (1.0 mm minimum).
