Red rectangular sensor with 2 m cable and screw adjustment

Banner

Banner Q60BB6AFV1000 adjustable-field sensor 2 m range

SKU CH-6665-HNBPM MPN Q60BB6AFV1000

Adjustable-field proximity sensor detects objects at 200-1000 mm with bipolar NPN/PNP output and 2 m cable

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Adjustable sensing field covers 200-1000 mm for flexible positioning
  • Bipolar NPN and PNP outputs simplify wiring into any control system
  • IP67 and NEMA 6 ratings withstand wash-down and dusty environments
  • Visible red LED beam at 640 nm eases alignment and setup
  • Operates from -20 °C to 55 °C for reliable use in cold or hot areas

2 m Adjustable-Field Sensor

The Banner Q60BB6AFV1000 is a rectangular proximity sensor with background suppression for industrial detection tasks. It suits engineers and technicians who need a visible red sensing beam and discrete bipolar outputs in a thermoplastic housing. The unit operates on 10-30 V dc supply voltage and includes a 2 m cable for direct wiring. It is built for environments requiring NEMA 6 and IP67 protection.

Detection Range and Output Limits

The sensing range adjusts from 200 to 1000 mm, providing flexibility for close and mid-range presence detection. Background suppression helps ignore objects beyond the set point, though performance drops past the 1000 mm maximum. The bipolar output delivers one NPN and one PNP channel with a 2 ms response time and 500 µs repeatability. Light or dark operate modes are selectable for application logic.

Voltage, Temperature and Cable Constraints

Supply voltage must stay within 10-30 V dc; the sensor draws power through its fixed 2 m cable with no quick-disconnect option. Operating temperature spans -20 °C to 55 °C with up to 90 % relative humidity at 50 °C. A 150 ms power-up delay occurs before the output stabilises. The acrylic lens and screw adjustment allow field tuning, while the 5-pin connection supports the discrete I/O interface.

Highlights

  • Adjustable sensing field covers 200-1000 mm for flexible positioning
  • Bipolar NPN and PNP outputs simplify wiring into any control system
  • IP67 and NEMA 6 ratings withstand wash-down and dusty environments
  • Visible red LED beam at 640 nm eases alignment and setup
  • Operates from -20 °C to 55 °C for reliable use in cold or hot areas

Specifications

BrandBANNER
ModelQ60BB6AFV1000
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

Will the 10-30 V dc supply range match the voltage of the older PLC I am keeping?

The sensor accepts any DC source between 10 V and 30 V, so it will operate from the same rail that powers your existing PLC.

How can I confirm the adjustable-field sensing is set correctly after mounting?

Watch the indicator LEDs while moving a target through the 200-1000 mm zone; the output switches at the exact distance you set with the screw adjustment.

Does the box include a mounting bracket or only the sensor with its 2 m cable?

The package contains the Q60BB6AFV1000 sensor with a 2 m 5-wire cable attached; mounting hardware is not included and must be sourced separately.
