Black 30 mm dome touch button with blue illumination and M12 connector

Banner

Banner K30APTXBF2Q 30 mm illuminated touch button

SKU CH-S32Z-Q9AH1 MPN K30APTXBF2Q

A 30 mm capacitive touch button with blue LED indication operates on 12-30 V dc and withstands IP67 and IP69K wash-down

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Capacitive touch activation with no moving parts to wear
  • IP67 and IP69K sealing resists wash-down and high-pressure cleaning
  • Blue LED status indication shows input-active state at a glance
  • M12 Euro quick-disconnect enables fast, tool-free installation
  • Wide 12–30 V dc supply range suits varied control systems

30 mm capacitive touch button

The Banner K30APTXBF2Q is a 30 mm illuminated touch button designed for industrial control panels and machine interfaces. It operates on a 12-30 V dc supply with a PNP normally open output, making it suitable for automation systems that require a sealed, low-profile operator input.

M22 × 1.5 thread with integral M12 quick-disconnect

The button mounts through a standard M22 × 1.5 cutout and connects via an integral 4-pin Euro-style quick-disconnect, reducing wiring time to a single plug-in step. The polycarbonate housing meets IP67 and IP69K ratings, so high-pressure washdown and temporary immersion do not affect operation, and the 2 m cable tail reaches most panel trunking without splicing.

One blue segment with pick-to-light function

A single blue LED segment indicates input activation while power is applied, supporting pick-to-light workflows at up to 55 mA per colour. The capacitive sensor responds in 300 ms on input and 150 ms on output, which is adequate for operator-paced tasks but too slow for high-speed safety or presence sensing. Operating limits are -40 °C to 50 °C with 90 % non-condensing humidity at 50 °C.

Highlights

  • Capacitive touch activation with no moving parts to wear
  • IP67 and IP69K sealing resists wash-down and high-pressure cleaning
  • Blue LED status indication shows input-active state at a glance
  • M12 Euro quick-disconnect enables fast, tool-free installation
  • Wide 12–30 V dc supply range suits varied control systems

Specifications

BrandBANNER
ModelK30APTXBF2Q
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How do I verify the touch button is operating correctly once installed?

Apply 12-30 V dc power and confirm the dome window lights blue when the capacitive surface is touched; the PNP output should switch within 150 ms.

What comes in the box and what must I source separately?

The box contains one K30APTXBF2Q button with an integral M12 Euro quick-disconnect; you must supply a compatible 4-pin M12 cable and a 12-30 V dc power source.

Which version should I choose for a pick-to-light station needing a single blue indication?

Select the F2 variant (part 88451) — it provides one blue segment, momentary touch actuation, and the required PNP normally-open output.
