White cylindrical hydraulic filter cartridge with two black end seals, 7-5/8 inches long

Baldwin Filters

Baldwin Filters P194HD10 Hydraulic Filter Element 7-5/8

SKU CH-SDMN-XT4H4

A hydraulic cartridge filter element with a 5‑micron rating and attached end seals, sized at 7‑5/8 inches for compatible equipment

  • TypeAutomotive Filters
  • 5-micron rating traps fine particles
  • 7-5/8 inch height fits specified housings
  • 6-1/32 inch diameter matches OEM dimensions
  • Includes two attached end seals for ready installation
  • Compatible with Caterpillar, John Deere and other listed equipment

Hydraulic Filter Element 7-5/8

The Baldwin Filters P194HD10 is a cartridge-type hydraulic filter element designed for heavy-duty equipment. It carries a 5 micron rating to capture fine contaminants in hydraulic systems. The unit includes two attached end seals for a secure fit. It serves operators who need reliable filtration for demanding mobile and stationary machinery.

Cartridge Design With Attached Seals

This element measures 7-5/8 inches in height and length with an outside diameter of 6 1/32 inches and an inside diameter of 1 23/32 inches. The cartridge format drops into a compatible filter housing without additional hardware. The attached end seals simplify installation and reduce the chance of seal misalignment. Builders who need a spin-on style or a different mounting interface cannot use this element.

Direct Replacement For Listed Applications

The P194HD10 replaces original equipment filters on Caterpillar, Quincy, Mack, Allis Chalmers, Case, Euclid, Gradall, John Deere, Koehring, CMC, Gardner-Denver and Ingersoll-Rand equipment where the P194, P194-HD, P194-HD10 or PF194 part numbers are specified. The jump is worth it when the existing element has reached its service interval or shows pressure drop. Systems requiring a different micron rating or thread size are not covered by this part.

Highlights

  • 5-micron rating traps fine particles
  • 7-5/8 inch height fits specified housings
  • 6-1/32 inch diameter matches OEM dimensions
  • Includes two attached end seals for ready installation
  • Compatible with Caterpillar, John Deere and other listed equipment

Specifications

BrandBALDWIN FILTERS
TypeAutomotive Filters

Questions about this item

How long does the 5 micron element last before flow drops off under continuous hydraulic use?

The 5 micron cartridge traps particles down to that size, so service life depends on the contamination level in your system rather than a fixed interval.

Does the cartridge run hot or add noticeable pump load during all-day operation?

The element itself has no moving parts and adds only the normal pressure drop of a 5 micron media; heat and noise come from the pump and fluid, not the filter.

What fittings or seal kit must I already have to install this 7-5/8 inch element?

The filter ships with two attached end seals, so you only need a compatible P194 series housing that accepts a 6 1/32 inch outside diameter cartridge.
