Compact black capture box with SDI input and USB-C output

AVMatrix

AVMatrix UC1118 SDI to USB 3.1 Type-C video capture

SKU CH-ZK4J-ARZRZ

Captures uncompressed SDI video up to 1080p60 via USB 3.1 Type-C at 200MB/s, driver-free and compatible with major streaming apps

  • TypeTV Tuner Cards
  • Driver-free setup lets you start streaming instantly
  • Automatic signal detection handles up to 1080p60 input without manual config
  • Uncompressed 200MB/s throughput over USB 3.1 Gen1 preserves full quality
  • UVC and UAC compliance works with Windows, Linux and macOS out of the box
  • Works directly in OBS, Zoom, Teams and Twitch with no extra software

UC1118 SDI to USB 3.1 Capture

The AVMatrix UC1118 converts an SDI signal to USB 3.1 Type-C for uncompressed video capture. It works without drivers or external power, making it practical for field production, live streaming and conference recording. Automatic input detection handles the signal format so the operator can focus on the shoot.

Up to 1080p60 uncompressed via USB 3.1 Gen1

The single specification that decides fit is the maximum supported format: 1080p at 60 frames per second delivered uncompressed over USB 3.1 Gen1 at up to 200MB/s. Any workflow requiring 4K, higher frame rates or compressed codecs will need different hardware.

Sustained uncompressed throughput at 200MB/s

Under continuous operation the device maintains the full uncompressed data rate of up to 200MB/s across the USB 3.1 Gen1 link. UVC and YUY2 compliance keeps the stream stable in OBS, Zoom, Teams or Twitch without dropped frames caused by driver overhead or host-controller bottlenecks.

Highlights

  • Driver-free setup lets you start streaming instantly
  • Automatic signal detection handles up to 1080p60 input without manual config
  • Uncompressed 200MB/s throughput over USB 3.1 Gen1 preserves full quality
  • UVC and UAC compliance works with Windows, Linux and macOS out of the box
  • Works directly in OBS, Zoom, Teams and Twitch with no extra software

Specifications

TypeTV Tuner Cards

Questions about this item

What does the 1080p60 rating mean when I plug this capture device into my computer?

The device captures SDI video at up to 1080p resolution and 60 frames per second, delivering full HD motion without frame drops over the USB connection.

How does the USB 3.1 Gen1 interface limit the capture performance in practice?

The USB 3.1 Gen1 link provides up to 200MB/s bandwidth, which is sufficient for the 1080p60 YUY2 stream without compression or frame loss.

What physical connections and mounting does the UC1118 need to work?

It needs a single SDI input cable and a USB Type-C port on the host; no external power supply or driver installation is required.
