Small black rectangular capture device with HDMI ports and USB cable

AVer RZ692K 4K HDMI to USB 2.0 Media Converter

SKU CH-C5ST-4HB9T

Captures 4K@60Hz HDMI video to USB 2.0 with 1080p output, plug-and-play across Windows, Mac, Linux and Android

  • FormatYUV/JPEG
  • Resolution Support4K
  • ColorBlack
  • Video1080p, YUV/JPEG
  • HDMI2 In
  • Serial Interfacehdmi
  • 4K capture at 60 Hz input with 1080p 30 Hz output
  • USB 2.0 plug-and-play works on Windows 7 8 10 Mac 10.9 Linux Android
  • Dual HDMI and dual component inputs for flexible source connection
  • Ultra-low latency HDMI pass-through keeps audio and video in sync
  • Aluminium shell design is compact and portable for mobile streaming

What this converter does

The AVer RZ692K captures 4K HDMI input at 60 Hz and delivers 1080p output at up to 30 Hz over a USB 2.0 link. It accepts two HDMI sources and two component sources, encoding video as YUV or JPEG. Streamers, teachers and remote workers can record or broadcast gameplay, lessons or conferences without installing drivers on Windows 8 or later, macOS 10.9 or later, Linux or Android.

Check your ports and OS first

Verify that your source device provides an HDMI or component output and that your computer has a free USB 2.0 port. The converter draws power from the USB bus so no external supply is needed. Confirm your operating system is Windows 7, 8 or 10, macOS 10.9 or later, Linux or Android; earlier versions are not supported. No HDMI cable is included in the package.

Fits a simple capture workflow

Connect a camera, console or second PC to either HDMI input, then plug the converter into your computer to appear as a standard video device in OBS, Zoom or similar software. The aluminium-alloy housing keeps the unit compact for desk or mobile use. It frees you from installing capture cards inside a chassis while still providing low-latency 1080p recording and streaming from 4K sources.

Highlights

  • 4K capture at 60 Hz input with 1080p 30 Hz output
  • USB 2.0 plug-and-play works on Windows 7 8 10 Mac 10.9 Linux Android
  • Dual HDMI and dual component inputs for flexible source connection
  • Ultra-low latency HDMI pass-through keeps audio and video in sync
  • Aluminium shell design is compact and portable for mobile streaming

Specifications

BrandAVer
SeriesVideo Capture Card
ModelVideo Capture Card
Part NumberRZ692K
FormatYUV/JPEG
Resolution Support4K
ColorBlack
Video1080p, YUV/JPEG
HDMI2 In
Serial Interfacehdmi
Network Interfacehdmi
USB Port1
Component2 In
Digital AduioYUV/JPEG
Other Connectorhdmi
SoftwareLinux, Mac OS(Mac OS 10.9 or later), Windows(Windows 8 and later),Android, Windows 7,8,10; Mac OS 10.9 or later, Linux
Software ApplicationLinux, Mac OS(Mac OS 10.9 or later), Windows(Windows 8 and later),Android, windows
DisplayChannel Editing
CompatibilityLinux, Mac OS(Mac OS 10.9 or later), Windows(Windows 8 and later),Android
System RequirementsWindows 7,8,10; Mac OS 10.9 or later, Linux
Power SupplyInstallation Guide, hdmi
SpecificationChannel Editing, Video Capture Card, hdmi, 1080p, YUV/JPEG, Windows 7,8,10; Mac OS 10.9 or later, Linux, 2.48 L x 1.06 W x 0.51 H inches, 0.059 kilograms
FeatureChannel Editing
Dimensions20'
Weight0.059 kilograms

Questions about this item

What does the box contain and what extra cables do I need?

The RZ692K media converter arrives with the capture unit and a USB 2.0 cable. An HDMI cable is not included, so you will need your own to connect a camera, console or other 4K source.

Which resolution and frame-rate combination should I select for my setup?

The device accepts 4K at 60 Hz on its HDMI inputs but outputs a maximum of 1920×1080 at 30 Hz over USB 2.0. Choose 1080p 30 Hz for broad software compatibility or 4K input when you need passthrough to a local display.

What does the 4K 60 Hz input figure mean once the converter is in my computer?

It means the RZ692K can ingest a 4K 60 Hz HDMI signal, but the USB 2.0 link limits recorded or streamed footage to 1080p at 30 Hz, so your recording software will receive 1080p even though the source is 4K.
