Small black rectangular capture card with HDMI and USB ports

AVer 4K HDMI Video Capture Card media converter Black

SKU CH-4YYE-6YCW2

Captures 4K HDMI input at 60 Hz and outputs 1080p video via USB 2.0 for streaming and recording

  • FormatYUV
  • Resolution Support4K
  • ColorBlack
  • Video1080p, YUV
  • HDMI2 In
  • Serial Interfaceusb2.0
  • Capture 4K input at 60 Hz for high-detail recordings
  • Output up to 1080p 60 Hz for smooth streaming
  • Plug-and-play over USB 2.0 with no driver install
  • Compact 64×28×13 mm design weighs only 21.4 g
  • Works with Windows, macOS, Android and consoles

4K HDMI capture for streaming

This AVer capture card accepts unencrypted HDMI input up to 4K at 60 Hz and delivers YUV or JPEG video at 1080p 60 Hz over USB 2.0. It targets streamers, educators and conference hosts who need a driver-free way to bring camera or console footage into OBS on Windows, macOS or Android. The compact black enclosure draws 0.4 A at 5 V and operates from -10 to +55 °C.

USB 2.0 host connection and system needs

The device plugs into a single USB 2.0 port and requires no external power supply. A host PC must provide at least an Intel Core i5-3400 or equivalent mobile i7-3537U at 2.0 GHz, a discrete GPU such as NVIDIA GT630 or GT735M, and 4 GB of RAM. HDMI sources connect via standard AWG26 cable up to 15 metres at 1080p; the card also offers two component inputs for legacy gear.

Sustained capture at 1080p 60 Hz

During long sessions the converter maintains 1080p 60 Hz output while ingesting 4K 60 Hz signals, writing directly to disk without added latency. The USB 2.0 bandwidth caps the recorded stream at 1080p, so producers needing 4K recording should note this ceiling. Thermal limits stay within the stated operating range for continuous indoor or outdoor use.

Highlights

  • Capture 4K input at 60 Hz for high-detail recordings
  • Output up to 1080p 60 Hz for smooth streaming
  • Plug-and-play over USB 2.0 with no driver install
  • Compact 64×28×13 mm design weighs only 21.4 g
  • Works with Windows, macOS, Android and consoles

Specifications

BrandAVer
Series4K HDMI Video Capture Card
Model4K HDMI Video Capture Card
Part NumberA-1
FormatYUV
Resolution Support4K
ColorBlack
Video1080p, YUV
HDMI2 In
Serial Interfaceusb2.0
Network Interfaceusb2.0
USB Port1
Component2 In
Other Connectorusb2.0
Softwarewindows,android,macOS, CPU: Intel Core i5-3400 or above or NB i7-3537U 2.0GHZ or above, Graphics card: NVIDIA GT630 or above or NVIDIA GT735M or above, RAM: 4GB
Display4K HDMI Video Capture at 60Hz
CompatibilityCamcorder, Personal Computer, windows,android,macOS, android, playstation, windows
System RequirementsCPU: Intel Core i5-3400 or above or NB i7-3537U 2.0GHZ or above, Graphics card: NVIDIA GT630 or above or NVIDIA GT735M or above, RAM: 4GB
Specification4K HDMI Video Capture at 60Hz, 4K HDMI Video Capture Card, usb2.0, 1080p, YUV, CPU: Intel Core i5-3400 or above or NB i7-3537U 2.0GHZ or above, Graphics card: NVIDIA GT630 or above or NVIDIA GT735M or above, RAM: 4GB, 6.1 L x 3 W x 1.7 H centimeters, 100 grams, Capture Card, Installation Guide
Feature4K HDMI Video Capture at 60Hz
Dimensions20'
Weight100 grams
Package ContentCapture Card, Installation Guide

Questions about this item

What is the maximum working current the AVer 4K HDMI Video Capture Card draws during sustained capture?

The card draws a maximum working current of 0.4A at 5V DC when capturing continuously.

How much heat does the capture card generate when running all day?

It operates within a temperature range of -10 to +55 degrees Celsius and weighs 21.4g, so passive cooling is sufficient for all-day use.

Which graphics card must the host computer already have for the capture card to function?

The system requires at least an NVIDIA GT630 on desktop or GT735M on notebook to meet the minimum GPU requirement.
