AUTYUE KVM Switch 3 Monitors 2 Computers 8K@30Hz/4K@120Hz HDMI 2.1 + 2 DP 1.4 USB 3.0 Wired Remote
Lets two computers share three monitors and USB 3.0 peripherals with 8K@30Hz or 4K@120Hz video via HDMI 2.1 and dual DP 1.4, switched by front buttons or wired remote
- TypeHDMI + 2 Displayport KVM Switch 2 Computers 3 Monitors
- Computer Connections2 Ports
- Monitor Connections3 Ports
- Video ResolutionThe resolution and fresh rate of triple monitor KVM switch s
- PC SelectionPush Buttons
- Monitors SupportedHDMI, Displayport, Displayport
- Share 3 monitors between 2 PCs with HDMI 2.1 and dual DP 1.4
- Switch instantly via front button or 1.5 m wired remote
- USB 3.0 ports deliver 5 Gbps for keyboard, mouse, printer
- Triple independent boards eliminate signal crosstalk
- DC 12 V adapter powers stable 8K 30 Hz and 4K 120 Hz operation
Triple-Monitor KVM Switch
This KVM switch lets two computers share three monitors, a keyboard, a mouse and audio. Each computer connects through two DisplayPort 1.4 inputs and one HDMI 2.1 input, while the three monitor outputs mirror that layout. A wired remote and front-panel buttons both change the active system. Three colour LEDs show which computer is selected.
Passive Cooling and External Power
The unit runs without fans, so it adds no noise to a quiet workspace. A 12 V DC adapter supplies all power for the switching logic and the downstream USB ports. Because the adapter is external, the switch itself stays compact and generates minimal heat during normal operation.
Build Integration Requirements
Each computer must provide two native DisplayPort 1.4 outputs and one native HDMI 2.1 output from a discrete graphics card; docking stations or integrated graphics will not drive three displays. Two USB 3.0 cables (1.5 m) and the wired remote (1.5 m) are included, so only video cables need to be sourced separately. The switch measures 8.27 x 3.07 x 1.18 inches and frees desk space by consolidating three monitor cables and peripheral connections into one device.
Highlights
- Share 3 monitors between 2 PCs with HDMI 2.1 and dual DP 1.4
- Switch instantly via front button or 1.5 m wired remote
- USB 3.0 ports deliver 5 Gbps for keyboard, mouse, printer
- Triple independent boards eliminate signal crosstalk
- DC 12 V adapter powers stable 8K 30 Hz and 4K 120 Hz operation
Specifications
| Series | KVM Switch 3 Monitors 2 Computers |
|---|---|
| Type | HDMI + 2 Displayport KVM Switch 2 Computers 3 Monitors |
| Computer Connections | 2 Ports |
| Monitor Connections | 3 Ports |
| Video Resolution | The resolution and fresh rate of triple monitor KVM switch supports up to 8K@30Hz/4K@120Hz backward compatible. |
| PC Selection | Push Buttons |
| Monitors Supported | HDMI, Displayport, Displayport |
| LED Indicators | Yes |
| Power Features | Come with DC 12V Power Adapter |
| USB Features | Triple monitor HDMI+2 Displayport KVM switch with 2 USB 3.0 ports which can recognize keyboard,mouse,printer,scaner and other USB devices. USB 3.0 offers data transfer speeds of up to 5Gbps |
| Application | 2 Displayport1.4+HDMI2.1 USB3.0 KVM Switch allows 2 computer to share 3 monitors and 2 USB3.0 ports(keyboard,mouse)+audio.It can make your work space tidy and efficient, also a premium choice for working from home. |
| Dimensions | 8.27 x 3.07 x 1.18 inches |
| Package Contents | 1*Triple Monitor USB3.0 KVM Switch+1*Wired remote controller(1.5m)+2*USB3.0 Cables(1.5m)+1*User manual+1*12V Power Adapter(1.52m). |
Questions about this item
How do I connect two PCs to three monitors using the HDMI 2.1 and two DisplayPort 1.4 inputs, and what is the most common mistake?
Connect 2×DP + 1×HDMI + 1×USB from each PC to the matching Input A/B/C and USB ports, then run 2×DP + 1×HDMI from the KVM outputs to the monitors; the step most people miss is using native GPU ports on a discrete card for all three connections per computer — docking stations or mixed GPU/IGPU ports will break the signal.
What maintenance will the DC 12 V power adapter and the three colour LEDs need over time?
The 12 V adapter (1.52 m cable) and panel LEDs are solid-state with no user-serviceable parts; keep the adapter vents clear of dust and replace the whole unit only if the LEDs stop showing the active PC or the switch loses power entirely.
At what resolution and refresh limit does the HDMI 2.1 / DP 1.4 link saturate first during sustained 8K or high-refresh 4K use?
The video path is rated for 8K@30 Hz or 4K@120 Hz maximum; pushing 8K beyond 30 Hz or 4K beyond 120 Hz will hit the bandwidth ceiling of the HDMI 2.1 and DP 1.4 interfaces first, causing signal drop-outs or forced downscaling.
