AUTYUE
AUTYUE 3-Port 2DP+HDMI KVM Switch 8K60Hz 4K144Hz
A 3-port KVM switch with two DisplayPort and one HDMI output lets three computers share three monitors, four USB 3.0 peripherals and a wired remote at up to 8K 60 Hz or 4K 144 Hz
- Type2 Displayport + 1 HDMI
- PC ConnectorsDP + DP + HDMI, USB 3.0
- Computer Connections3 Ports
- Monitor Connections3 Ports
- Video ResolutionThe dual display port port supports 8K@30Hz, 4K@144Hz, 3440x
- PC SelectionPush Buttons
- Share three computers across three monitors with 2 DP + 1 HDMI outputs
- Switch instantly via front button or 1.5 m wired remote
- Four USB 3.0 ports share peripherals at up to 5 Gbps
- HDMI port delivers 8K at 60 Hz; DP ports reach 4K at 144 Hz
- Driver-free operation on Windows, macOS, Linux and Chrome OS
Three-computer KVM switch with triple-monitor output
This AUTYUE KVM switch lets three computers share one keyboard, one mouse and three monitors connected through two DisplayPort inputs and one HDMI input. It is aimed at users who need to control multiple PCs from a single desk without swapping cables. The unit ships with all required cables, a wired remote and a 12 V power adapter.
Dual DisplayPort 1.4 and HDMI 2.1 video interfaces
The two DisplayPort ports each support 8K at 30 Hz, 4K at 144 Hz and 3440×1440 at 144 Hz, while the HDMI port supports 8K at 60 Hz and 4K at 60 Hz. Both interfaces are HDCP 2.3 compliant, so protected content plays correctly across all three screens.
Passive cooling with external 12 V adapter
The switch draws power from the included 12 V adapter and has no internal fan, so it runs silently in normal use. USB 3.0 ports provide up to 5 Gbps data transfer for shared peripherals, and the unit operates without additional driver software on Windows, macOS, Linux and Chrome OS.
Highlights
- Share three computers across three monitors with 2 DP + 1 HDMI outputs
- Switch instantly via front button or 1.5 m wired remote
- Four USB 3.0 ports share peripherals at up to 5 Gbps
- HDMI port delivers 8K at 60 Hz; DP ports reach 4K at 144 Hz
- Driver-free operation on Windows, macOS, Linux and Chrome OS
Specifications
| Type | 2 Displayport + 1 HDMI |
|---|---|
| PC Connectors | DP + DP + HDMI, USB 3.0 |
| Computer Connections | 3 Ports |
| Monitor Connections | 3 Ports |
| Video Resolution | The dual display port port supports 8K@30Hz, 4K@144Hz, 3440x1440@144Hz, 4K@60Hz, 2K@144Hz, 1080P. The HDMI port supports 8K@60Hz, 4K@60Hz and backward compatibility. |
| PC Selection | Push Buttons |
| Monitors Supported | 2 Displayport + 1 HDMI Triple Monitors |
| LED Indicators | Yes |
| Power Features | Requires no additional power supply |
| USB Features | with USB support |
| Application | This USB 3.0 KVM switch HDMI +2 display port is very suitable for devices with DP and HDMI interfaces, so 3 computers can share a set of mouse, keyboard and monitors. Press "Windows+P" to select the mirror screen or extended display screen. |
| Features | 3 computers share 3 monitors and 4 USB device. Supports wired or wireless keyboard and mouse. Support resolutions up to 8K 60Hz,4K 144Hz. USB 3.0 with ultra-fast data transfer up to 5Gb/s. |
| Dimensions | About 6.3 x 2.56 x 1.77 inches |
| Weight | About 14.46 ounces |
| Package Contents | 1*Triple Monitor KVM Switch; 3*USB3.0 Cables(1.5m/4.9ft); 1*Wired remote controller(1.52m/5ft); 1*User manual; 1*12V Power Adapter(1.52m/5ft). |
Questions about this item
What does the 8K 60 Hz figure mean when I plug this into my PC?
The HDMI port can output 8K at 60 Hz; each DisplayPort port reaches 8K at 30 Hz, 4K at 144 Hz or 3440×1440 at 144 Hz.
Which video standards do the ports follow and what bandwidth do they cap at?
The HDMI port follows HDMI 2.1 and the two DisplayPort ports follow DisplayPort 1.4, both with HDCP 2.3.
How much desk space and cabling does the unit need to fit three computers and three monitors?
The switch measures 6.3 × 2.56 × 1.77 inches and weighs 14.46 ounces; each PC requires one HDMI cable, two DisplayPort cables and one USB 3.0 cable, all 1.5 m long, plus a 1.52 m wired remote and a 12 V power adapter.
