ATEN CS782DP 2-Port 4K UHD DisplayPort KVM Switch
Controls two 4K DisplayPort computers from one keyboard, mouse and monitor with hotkey, mouse or remote switching
- TypeDisplayPort, USB
- PC Connectors2 x USB Type B Female (White) 2 x DisplayPort Female (Black)
- Console Connectors2 x USB Type A Female (Black) 1 x DisplayPort Female (Black)
- Computer Connections2 Ports
- Video Resolution4K UHD (3840 x 2160 @ 60Hz)
- PC SelectionHotkey, Mouse, Remote Port Selector
- Control two 4K computers from one console
- Switch instantly via hotkeys, mouse or remote selector
- Enjoy 3840×2160 at 60 Hz video clarity
- Hear HD audio through 2.1 channel support
- Compact 1.06×3.66×3.66 in design saves desk space
2-Port 4K UHD DisplayPort KVM Switch
The ATEN CS782DP lets you control two USB computers from one DisplayPort monitor, keyboard, and mouse. It supports 4K UHD resolution at 60 Hz for graphic design, animation, and video editing workflows. Audio switching includes 2.1 channel support through DisplayPort playback.
Check your computer video outputs and USB ports
Both host systems must provide DisplayPort 1.2 signals and USB Type B ports for the KVM cables. Verify that your monitor accepts DisplayPort input at 3840 x 2160 @ 60 Hz. Ensure 3.5 mm audio jacks are available if you need switched analogue sound.
Compact metal chassis with front-panel switching
The unit measures 1.06 x 3.66 x 3.66 inches and weighs .26 lb, fitting easily on a crowded desk. White KVM LEDs show the active port at a glance. A wired remote port selector, hotkeys, and mouse gestures give three ways to switch without reaching the box.
Highlights
- Control two 4K computers from one console
- Switch instantly via hotkeys, mouse or remote selector
- Enjoy 3840×2160 at 60 Hz video clarity
- Hear HD audio through 2.1 channel support
- Compact 1.06×3.66×3.66 in design saves desk space
Specifications
| Brand | ATEN |
|---|---|
| Model | CS782DP |
| Type | DisplayPort, USB |
| PC Connectors | 2 x USB Type B Female (White) 2 x DisplayPort Female (Black) 2 x 3.5mm Audio Jack Female (Green) |
| Console Connectors | 2 x USB Type A Female (Black) 1 x DisplayPort Female (Black) 1 x 3.5mm Audio Jack Female (Green) |
| Computer Connections | 2 Ports |
| Video Resolution | 4K UHD (3840 x 2160 @ 60Hz) |
| PC Selection | Hotkey, Mouse, Remote Port Selector |
| AutoScan Interval | 3, 5, 10, or 20 seconds |
| LED Indicators | KVM 2 (White) |
| Temperature | Operating Temperature 0 – 50°C Storage Temperature –20 – 60°C |
| Humidity | Humidity 0 - 80% RH, Non-condensing |
| Features | One DisplayPort video console controls two USB computers Fully DisplayPort 1.2 Compliant Computer selection via remote port selector, hotkeys, and USB mouse1 Superior video quality – up to 4K UHD (3840 × 2160@60Hz) Multiplatform support – Windows, Mac, Sun, Linux HDCP Compliant Supports MST (Multi-Stream Transport)2, enabling multiple monitors to be used via a single DisplayPort connector Supports DisplayPort Dual Mode (DP++)3 for directly outputting single-link DVI or HDMI signals via a powered DisplayPort-to-HDMI/DVI DP++ adapter Compatible with widescreen LCD monitors Power on det |
| Dimensions | 1.06" x 3.66" x 3.66" |
| Weight | 0.26 lb. |
| Shipping weight | 0.73 kg |
| Package size | 239 × 170 × 61 mm |
Questions about this item
Does the CS782DP ship with cables to connect both computers, or must they be purchased separately?
The box contains the KVM switch, a remote port selector, and a power adapter; two USB Type-B cables and two DisplayPort cables are required per computer and are sold separately.
Which version of the CS782DP should I pick for dual 4K monitors at 60 Hz?
The CS782DP is a single model supporting one DisplayPort console at 3840 x 2160 @ 60 Hz; it does not drive dual monitors, so no alternate version exists for that purpose.
What does the 3840 x 2160 @ 60 Hz rating mean when the switch is installed in my system?
It guarantees that each connected computer can output full 4K UHD at 60 frames per second through the switch to a single DisplayPort monitor without downscaling or refresh-rate loss.
