ATEN CS1964 4-port USB 3.0 4K DisplayPort triple display KVM switch

ATEN

ATEN CS1964 4-Port USB 3.0 4K DisplayPort Triple Display KVM Switch

SKU CH-7N3N-9KX2X MPN CS1964

Controls four computers across three 4K displays with USB 3.0 hub and 15-key rollover support

  • TypeConsumer Electronics
  • Manage four computers with one keyboard and mouse
  • Support three monitors at 4096 x 2160 @ 60Hz resolution
  • Transfer data at up to 5 Gbps via USB 3.1 Gen 1 hub
  • Switch displays faster with patented Video DynaSync technology
  • Type up to 15 simultaneous keystrokes without ghosting using N-key Rollover

Triple-Display 4K KVM Switch

The ATEN CS1964 lets you control four computers from one keyboard, one mouse and three DisplayPort monitors running up to 4096 x 2160 at 60 Hz. It is built for professionals who need simultaneous multi-screen visibility across several systems.

Upgrade From Single-Monitor Or Two-Port KVMs

If you currently juggle multiple keyboards or rely on a dual-head switch, this unit adds a third 4K output and two extra computer ports without losing USB 3.1 Gen 1 throughput at 5 Gbps. The jump is worthwhile when workflow demands three synchronous 4K views across four hosts.

Check DisplayPort Outputs And USB Ports On Each Host

Every computer must provide three DisplayPort video outputs and at least one USB 3.0 port for the KVM link. Verify that your graphics cards support 4K DCI resolution at 60 Hz and that desk space accommodates three monitors.

Highlights

  • Manage four computers with one keyboard and mouse
  • Support three monitors at 4096 x 2160 @ 60Hz resolution
  • Transfer data at up to 5 Gbps via USB 3.1 Gen 1 hub
  • Switch displays faster with patented Video DynaSync technology
  • Type up to 15 simultaneous keystrokes without ghosting using N-key Rollover

Specifications

BrandATEN TECHNOLOGIES
TypeConsumer Electronics
Shipping weight4.54 kg
Package size635 × 356 × 178 mm

Questions about this item

How many DisplayPort cables and USB 3.0 cables are required to connect the three monitors and four computers?

You need three DisplayPort cables for the monitors and four USB 3.0 cables to link each computer to the switch.

What is the correct order for powering on the CS1964 and the connected computers to ensure Video DynaSync detects the displays?

Power on the CS1964 first, wait for it to initialise, then turn on the computers so the EDID data is captured correctly.

How often should the USB 3.1 Gen 1 hub ports be inspected for dust or debris to maintain 5 Gbps transfer rates?

Check the hub ports every few months and use compressed air to clear any dust that could affect the 5 Gbps data throughput.
